SHY-6 diamond core drill utilizes an advance load sensing control system within it's hydraulic system, which is currently being adopted by the major international producers. The rig features quality pedrail tracks that provides the rig with strong climbing capabilities that enhances it's capabilities even in the toughest terrain.
Applications:
Diamond core drilling
Directional drilling
Reverse circulation continuous coring
Percussion rotary
Geo-tech
Water bores
Anchorage
Product Features:
The rig offers a smooth hydraulic transmission, operating at low noise levels. Whilst providing convenience to the operation is labor saving and focuses on promoting work safety on site.
The whole hydraulic system of the drill is adopted international advanced load- sensitive control system, efficient and sumptuary, main hydraulic elements are all original imported, stable using and reliability.
The predrail set has high driving force and powerful climbing ability.
The rotation head is step-less speed transmission, offering a wide rang of speeds and torque(uo to 3 speeds), the rotation head can be side racked via hydraulic rams for added convenience and efficiency especially during rod trips.
Hydraulic chuck jaws and foot clamps offers a fast clamping action, designed to be reliable, neutral. The foot clamps are designed to suit various different drill rod sized via the use of different size slip jaws.
Feed stroke at 3.5meters, reduces operation time, improves drilling efficiency and reduces inner tube core blockages.
Braden main winch (USA) features s stepless speed transmissions from Rexroth. Single rope hoist capacity up to 8.1 ton. Wireline winch is also equipped with a stepless speed transmission, offering a wide speed range.
The rig benefits from a tall mast, which allows for the operator to pull rods at up to 6m lengths, making rod trips faster and more efficient.
The mast could be folded to decrease the transport size and fulfill the civil road transportation statuse. The drilling rig could be transported in container.
Equipped with all the essential gaues including:
Rotation speed
Feed pressure
Ammeter
Voltmeter
Main pump/torque gauge
Water pressure gauge
Enabling the driller to oversee the entire operation of the drill rig at a simple glance.
Technical Parameters
Model
SHY-5A
SHY-5C
SHY-6
Diesel Engine
Power
145kw
145kw
175kw
Drilling Capacity
BQ
1500m
1500m
2000m
NQ
1300m
1300m
1600m
HQ
1000m
1000m
1300m
PQ
680m
680m
1000m
Rotator Capacity
RPM
0-1050rpm
0-1100rpm
0-1100rpm
Max.Torque
4650Nm
4600Nm
6400Nm
Max.Lifting Capacity
15000kg
15000kg
220kn
Max.Feeding Power
7500kg
7500kg
110kn
Foot Clamp
Clamping Diameter
55.5-117.5mm
55.5-117.5mm
55.5-117.5mm
Main hoister lifting force(Single rope)
7700kg
7700kg
120kn
Wire hoister lifting force
1200kg
1200kg
15kn
Mast
Drilling Angle
45°-90°
45°-90°
45°-90°
Feeding Stroke
3200mm
3200mm
3200mm
Slippage Stroke
1100mm
950mm
1100mm
Other
Weight
8500kg
7000kg
9600kg
Transport Way
Crawler
Trailer
Crawler
