| Price: | US $ 500-1000/Set |
|---|---|
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,Western Union |
Features:
1. Control by foot or hand Pedal
2. Punching Power:1 Ton to 4 Tons
3. Compact and safely structure
Application:
Used in punching, bending, blanking, cutting, riveting, etc. this machine usage with die, safely and high efficiency operate, using high quality material, make sure the edge of finished products beautiful and smooth. the methods of punch card you can choose by yourself, for example, the punch method of adjust edge distance and fixation punch method.
Technical parameter:
| Model | JB01 | JB02 | JB03 | JB04 | JB05 |
| Nominal press capacity (KN) | 10 | 20 | 30 | 40 | 50 |
| Stroke of slide (mm) | 40 | 42 | 48 | 42 | 42 |
| Stroke of nominal pressure(mm) | 2.4 | 2.4 | 2.4 | 2.4 | 2.4 |
| Stoke per minute (s.p.m) | 250 | 220 | 200 | 200 | 180 |
| Max. shut height(mm) | 150 | 220 | 250 | 250 | 270 |
| Distance between columns (mm) | 106 | 130 | 230 | 230 | 230 |
| Throat depth (mm) | 58 | 65 | 85 | 65 | 65 |
| Shank hole size (mm) | 20*40 | 20*45 | 28*50 | 25*40 | 25*40 |
| Bench size (mm) | 300*275 | 320*300 | 400*380 | 350*370 | 430*370 |
| Slider bottom size(mm) | 57*48 | 72*64 | 80*70 | 78*78 | 78*78 |
| Motor power(w) | 370 | 450 | 650/750 | 650/750 | 650/750 |
| Dimension(mm) | 495*375*555 | 520*400*620 | 640*550*830 | 720*570*900 | 720*570*900 |
| Weight(kg) | 95/100 | 115/120 | 240 | 250-360 | 270-380 |
For more detailed specifications please feel free to contact with us
Jining Bafang Mining Machinery Group Co.,Ltd
Name:Mavis Zhang
Telephone:86-537-2228876 +13012657265
| Prod Model: | JB |
|---|---|
| Type: | High-Speed Punching Machine |
| Controlling Mode: | CNC |
| Automatic Grade: | Manual |
| Power Source: | Electric |
| Precision: | High Precision |
