Single Knife Hydraulic Rubber Bale Cutter, Rubber Cutting Machine Xql-80

Single Knife Hydraulic Rubber Bale Cutter, Rubber Cutting Machine Xql-80
Price: US $ 8000set
Trade Terms: FOB,CFR,CIF
Min Order: 1set
Pay Type: L/C,T/T,Western Union,Paypal
Prod Model: XQL-80
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type: Tire Machinery
Type Of Tire Machinery: Tire Building Machine
Weight: <50 Tons
Power: >100kw
Voltage: 380V
Using Life: ≥15 Years
Warranty: 2 Years
Type Of General Rubber Machinery: Rubber Cutter
Name: Rubber Bale Cutter
Function: Rubber Cutting

Product Description

  Single Knife Hydraulic Rubber Bale Cutter, Rubber Cutting Machine Xql-80



Usage of rubber bale cutter:

This rubber bale cutter is mainly used to cut the natural rubber,synthetic rubber and other plastic materials,especially it is suitable to be installed near the rubber mixer to cut small pieces of rubber.

Features of rubber bale cutter:

1.This rubber bale cutter mainly consists of cutting knife,frame,cylinder,base,auxiliary table,sydraulic system and electric system.

2.The nylon plate is installed on the base under the cutting knife for protecting the edge of the cutting knife.

3.When cutting the raw rubber,put the raw rubber under the cutting knife,the press the start button,the knife can cut the rubber.

5.Two limited switches are installed on the frame to control the reversal valve to change the movement direction of the knife,at the same time,it protects the cover of the cylinder.



Technical Information:

TypeXQL-8XQL-16
Width (mm)6601000
Stroke (mm)680680
Diameter of the piston (mm)150150
Time Taken by the Stroke (second)16~2510~16
Power (KW)5.55.5
Overall Dimension (LxWxH)1900×720×25802240×720×2580
Weight (kg)15002000








  • We have many years' sales experiences; we accept various payment methods for your convenience.
  • Multiple protection methods are applied to the machine in order to lower potential risks during delivery process, we are trying to make our service better to make sure every set of machine is delivered perfectly.




Our packing way :Export standard (wooden package )  or according to your requirement .



Our Services :

1. We will design,manufacture,install and test the machines according to  customers' requirement .Relevant personnel  training for customers,ensure that customers fully grasp the use and maintenance of technology.



2 .Our service department  listen to customers' feedback at any time and provide spare parts timely.Welcome to visit our factory and we can show you the machine in working condition:



If our products win your interest, please send us inquires and we will provide detailed information to you. We can also make machines according to your request.


Qingdao Qishengyuan Mechanical Manufacturing Co., Ltd. Was located in beautiful Jiaonan the west coast of Qingdao city Shandong province China. Our company is specialize in Rubber machinery production enterprise with R & D, design, production, sales and service.

The company covers an area of 12000 square meters, construction area of 8000 square meters, with self import and export rights, and has passed the ISO9001: 2008 & CE quality management system certification, Great Service is our mission. Hight Quality is our Obligation.

Our Company by virtue of years of production technology, We have rich experience technicians, We specialized produce Rubber two roll mixing mill machine, Rubber crusher mill machine, Rubber Kneader machine, rubber calender machine, rubber press vulcanizer machine, rubber refiner machine, waste tire recycling plants, Batch off cooling plants, rubber cutting machine, rubber strainer machine, Tires production line, Conveyor belt production line and so on.

We can design the machine as customer requires.
