North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cable Diameter Szie:
0.9mm,1.6mm,1.8mm,2.0mm,2.4mm,2.8mm,3.0mm
Cable Jacket Color:
Blue,Orange,Yellow,Aqua, Magenta,Black, Gray,Pink
Cable Jacket Material:
Lszh,PVC, Ofnr, Ofnp, PE, Rised
Connector Housing Color:
Blue,Orange,Yellow,Aqua, Magenta,Black, Gray,Pink
Cable Length:
1m, 2m, or Customization
Label:
Sticker, Paper
Boot Type:
LC Uniboot, Slotted Boot, Smooth Boot, Rubber Boo
Application:
Communication
Type:
Single-mode Fiber
Certification:
ISO9001
Connection Structure:
Sc/FC/LC/St/Mu
Core:
Single Core, Double Core,Multicore
Product Description
With 15 years history, KOC is a well-established brand popularly accepted in the world-wide market, especially in European and American countries. We are a professional manufacturer of most passive parts such as patch-cord, connector, adapter, attenuator,splitter, WDM serious. For more detail, please check on our website www.koc.com.cn.
In case of need, please do not hesitate in contacting us.
APPLICATIONS CATV Telecommunication networks Active device termination Metro Local Area Networks (LANs) Data processing networks Test equipment Premise installations Wide Area Networks (WANs)
FEATURES Low insertion loss and back reflection loss Good exchangeability Good Durability High temperature stability Standard: Telcordia GR-326-CORE SPECIFICATIONS
Single mode
Multimode
Insertion Loss
Typical≤0.2dB, Maximum≤0.3dB
≤0.25dB
Return Loss
≥50 dB (PC) ≥60 dB (APC)
≥30 dB
Repeatability
≤0.1
Durability
≤0.2 dB typical change, 1000 matings
Interchangeability
≤0.2dB
Tensile strength
>70N
Operating Temperature
-40 to + 85°C
ORDERING OPTIONS
Connector Color
Boot (cable) Size
Boot Color
Fiber Type
Cable number
Application
Length
Beige
0.9mm
Beige
9/125μm (SM)
Simplex
PC
Customized
Blue
2.0mm
Black
50/125μm(MM)
Duplex
APC
Green
3.0mm
Blue
62.5/125μm(MM)
Fan-out (4f)
Green
Fan-out (6f)
Gray
Fan-out (8f)
Red
Fan-out (12f)
White
Fan-out (24f)
Note: The price range is for FC/UPC-FC/UP Singlemode Simplex 3.0mm 5meter.
Shenzhen KOC Communication Co., Ltd. Is specialized in fiber optic communication product manufacture. Our products range from the basic components to end products, including passive and active categories as follows: Basic Components: Connector kits, Adapter kits, Attenuator kits.
Passive products: Connector, Adapter, Attenuator, Patch-cord, ODF and enclosure.
Active products: Media converter, Transmitting and receiving assemblies, such as laser diode assembly, PD and PIN/TIA assembly, sub-assemblies such as TOSA, ROSA, BOSA.
FTTH System: Gpon: OLT, ONU, PLC
Headquarter located in Shenzhen, China, we have branch companies, representatives and distributors in Europe, America, Middle East, South Asia. KOC products are well accepted and sold in these areas.
We provide all our products with high quality, competitive price, short delivery lead time and excellent after-sales services.
About KOC
Located in Shenzhen, China, KamaxOptic Communication Co. Ltd., well-known as KOC, is specialized in fiber optic communication products and accessories. She offers precise customized solutions for various customers involved in telecommunication, broadcast, CATV and network industry worldwide.
Our quality is guaranteed by the scientific management with the assistances of professional personnel, advanced testing equipments and efficient ERP system under the strict guidance of ISO9001: 2000, from supplier evaluation to inbound material examination, from processing monitoring to permanent inspection, from packing to shipping. We do care for every detail!
To be dedicated to be a popular manufacturer with her quality products, satisfactory services and attention to details through the full commitment of each personnel to work as one team in an effort to exceed our customer expectations.
To operate the business in a transparent and honest manner, that our customers, our associates and our business partners are proud to play their part in our success.
Please visit us website for more information: http://www.koc.com.cn
