Curtis controller 1266A-5201, 275A, imported from USA directly
Curtis controller 1234E-5221, 275A, imported from USA directly
Motor
ADC brand Separately excited DC motor 48V 3.7kw
ADC brand Separately excited AC motor 48V 3kw
Battery
Trojan battery, T875,8V*6pcs, imported from USA directly
Trojan battery, T875,8V*6pcs, imported from USA directly
Transaxle
Italian GRAZIANO axle with gear ration 1:12
Italian GRAZIANO axle with gear ration 1:16
Charger
High Frequency onboard charger 48V/17A regulator
High Frequency onboard charger 48V/17A regulator
Performance
Item
Description
system
DC system
AC system
Passenger Capacity
4
4
Climbing capacity(full load)
30%
35%
Max. forward speed
23km/h
45km/h
Endurance mileage
70-90km
80-90km
Charging time
8-10 hours
8-10 hours
Max. loading weight
360kgs
360kgs
Min. turning radius
2.9m
2.9m
Max. movement after brake at speed of 20km/h
≤4m
≤4m
* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree; 2) Range will vary depending on temperature, grade, payload and driving style. Dimensions
Item
Description
Overall dimensions (L x W x H)
2921x1219x1727mm
Ground clearance
114mm
Wheelbase
1670mm
Front wheel tread (mm)
860mm
Rear wheel tread (mm)
970mm
Body and Frame
Item
Description
Frame & Chassis
Aluminum alloy beam, bended
Body
PP engineering plastic front and rear body cover, injected
Roof
Glass fiber reinforced plastic
Windshield
Organic glass (PMMA), one-piece or two pieces
Roof supports
Imbedding black coating steel tube in the plastic support
Cushion
Reborn sponge with artificial leather and plastic bottom cover
Backrest
Reborn sponge with artificial leather and plastic cover
Armrest
Plastic
Floor mat
Anti-skidding rubber
Rear basket
Plastic
Golf bag holder
Plastic support with nylon strap
Dashboard
Black plastic material, battery power indicator, ignition key on it
Beverage holders
4 pcs cups holders, 2 pcs for each side
Side trim
Plastic, black
Score card holder
On the steering wheel
Electric System
Item
Description
Lights
48V, LED headlight (includes turning light and position light), LED taillights (includes brake lights and turning light),
Horn
Electric horn, 48V
Reverse buzzer
Electric, 48V
Combination switch
Control the lights and horn
Digital Meter (optional)
Including kilometer indicator, speed indicator, overload indicator, parking brake indicator, clock
Steering & suspersion
Item
Description
Steering System
Self-adjusting rack and pinion steering system, with automatic compensation function
Brake System
Rear wheel mechanical brake
Accelerator
Holzer type, stepless speed change
Front suspension
Mcpherson independent spring suspension
Rear suspension
Coil spring hydraulic shock absorber
Driving model
Rear axle two stage deceleration, motor direct driving
Wheel & Tyre
Aluminum wheel & USA Carlisle 18*8.5-8 6 layers
Option Accessories To increase the sales value of our golf cart, we also provide many optional accessories.
Item
Option description
Item
Option description
1
E-key
11
2-point seatbelt
2
Hinged windshield
12
Battery water refill system
3
Laminated windshield with wiper
13
Digital meter
4
Steel brush guard
14
EM brake
5
Front steel basket
15
Four wheel disc brake
6
Inner rear view mirror
16
Carlisle 205/50-10 tyre with10inch wheel
7
Side rear view mirror
17
Ice box
8
Enclosure
18
Sand bottle
9
Sunshine cover
19
Sand rake
10
Golf bag cover
20
Ball washer
Body and Frame
Item
Description
Frame & Chassis
Aluminum alloy beam, bended
Body
PP engineering plastic front and rear body cover, injected
Roof
Glass fiber reinforced plastic
Windshield
Organic glass (PMMA),one-piece or two pieces
Roof supports
Imbedding black coating steel tube in the plastic support
Cushion
Reborn sponge with artificial leather and plastic bottom cover
Backrest
Reborn sponge with artificial leather and plastic cover
Armrest
Plastic
Floor mat
Anti-skidding rubber
Rear basket
Plastic
Golf bag holder
Plastic support with nylon strap
Dashboard
Black plastic material, battery power indicator, ignition key on it
Beverage holders
4 pcs cups holders, 2 pcs for each side
Side trim
Plastic, black
Score card holder
On the steering wheel
