Mini 10.1 Inch touch screen monitor/display for industrial applications with EETI touch
Model
B101-RT
Screen Size
10.1"
Material
Aluminum bezel with Metal housing
Screen
True flat tempered glass
Resolution
1280*800 pixels IPS panel
Contrast Ratio
500:1
Brightness
250 nits
Aspect Ratio
16:10
Color Depth
16.2 M
Viewing Angle (H/V)
178°/178°
Pixel Pitch (H*V)
0.1695*0.1695 mm
Viewing Size (H*V)
216.96*135.6 mm
Response Time (Tr/Tf)
25 ms
Touch Structure
G+G
Touch Type
Projected Capacitive touch
Max Support
10 touch points
Touch Controller
Industrial EETI or Consumer ILITEK
Built-in Function
VGA+AV+BNC+HDMI+USB2.0 Touch
Language
Chinese, English, Russian, French, Spanish, German, Italian
Power Supply
12 VDC Input with 110-240 VAC power adapter, 50/60 Hz
Installation
VESA mounting; Optional for Open Frame
Operating Temperature
0~50ºC
Storage Temperature
-20~60ºC
Humidity
10%-90%
Product Size
26.2*18.4*3.9cm
Product New Weight
1.27 KGS
Included Accessories
Manual, Warranty Card, Wall Mount Bracket, Power Adapter, VGA Cable, USB Cable
Regulatory Compliance
CE/FCC/RoHs/CCC
Shenzhen Bolinia Technology Co., Ltd. is a manufacturer for 7-32 inch lcd monitors and displays over 13 years. Original factory with assembling line in Shenzhen. Product ranges from plastic monitor, metal monitor, resistive touch monitor, capacitive touch monitor, open frame monitor, embedded monitor to SDI broadcasting monitor. Square monitor or wide screen monitors are available with different resolutions. Newly launched 10.1-32 inch All in One PC and portable LCD monitors.
Plastic or metal casing monitor from 7 inch to 24 inch. Single touch monitor with resistive 4 wire and 5 wire for options from 7 inch to 22 inch. Multi-touch projected capacitive touch (PCAP Touch or PCT) monitor from 8 inch to 24 inch. SDI monitor from 15 inch to 21.5 inch. High brightness monitor from 10 inch to 22 inch. Mirror Image Monitor with size: 8 inch, 9.2 inch, 10.4 inch, 12.1 inch, 15 inch, 17 inch, 19 inch, 20.1 inch and 22 inch. All in One PC with Android system with 10.1 inch, 13.3 inch, 15 inch, 15.6 inch, 18.5 inch, 21.5 inch, 23.6 inch, 24 inch, 27 inch and 31.5 inch. Portable LCD monitor with 12.5 inch, 13.3 inch and 15.6 inch.
Products mainly used in ATM, POS, CCTV security, Information checking, Kiosk, BGA repairing station, Lottery terminals, microscopes and similar applications. Portable LCD monitors perfectly compatible to PS4/PS3/PS2/Xbox ONE/Xbox 360, game consoles, PCs, Macs, Raspberry Pi, laptops, cameras and tablets.
Shenzhen Bolinia Technology Co., Ltd. is a manufacturer for 7-32 inch LCD monitors and displays over 13 years. Original factory with assembling line in Shenzhen. Product ranges from plastic monitor, metal CCTV monitor, resistive touch monitor, capacitive touch monitor, open frame monitor, embedded monitor to SDI broadcasting monitor. Square monitor or wide screen monitors are available with different resolutions. Newly launched 10.1-32 inch All in One PC and portable LCD monitors.
Reliable quality used in Olympic Games.
Plastic or metal casing monitor from 7 inch to 24 inch.
Single touch monitor with resistive 4 wire and 5 wire for options from 7 inch to 22 inch.
Multi-touch projected capacitive touch (PCAP Touch or PCT) monitor from 8 inch to 24 inch.
SDI monitor from 15 inch to 21.5 inch.
High brightness monitor from 10 inch to 22 inch.
Mirror Image Monitor with size: 8 inch, 9.2 inch, 10.4 inch, 12.1 inch, 15 inch, 17 inch, 19 inch, 20.1 inch and 22 inch.
All in One PC with Android system with 10.1 inch, 13.3 inch, 15 inch, 15.6 inch, 18.5 inch, 21.5 inch, 23.6 inch, 24 inch, 27 inch and 31.5 inch.
Portable LCD monitor with 12.5 inch, 13.3 inch and 15.6 inch.
Products mainly used in ATM, POS, CCTV security, Information checking, Kiosk, BGA repairing station, Lottery terminals, microscopes and similar applications. Portable LCD monitors perfectly compatible to PS4/PS3/PS2/xBox ONE/xBox 360, game consoles, PCS, Macs, Raspberry Pi, laptops, cameras and tablets.
