Product Name:
LED Screen
Driver IC:
Mbi5124
Bightness CD/Sqm:
1200CD
Grey Scale:
65536 Degree
Life Time:
More 100, 000 Hours (80%)
LED Screen Mtbf:
More 50, 000 Hours
Operating Temperature:
-30~-60t
LED Display Humidity:
10%-95%
Color Temperature:
6500K-9500K
Warranty:
3 Years
Tube Chip Color:
Full Color
Display Function:
Market Display
Pixel Pitch:
4mm
Pixel Configuration:
1R,1G,1B
Scanning Mode:
1/16 Scan
System Operating Platform:
WIN XP
Display Type:
LED Video Display
Application:
Shopping Guide
IP Rating:
IP40
Certification:
ETL
Pixel Density:
62500dots Per Sqm
Product Description
Indoor HD P2.5 P3 P4 Full Color LED display panel for LED display screen tel:+86 18923415589
LED screen Professional production: Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen
Product descripition:
NO.:
Product name
indoor P4 Full Color LED Display Screen l
1
Pixel Pitch(mm)
4mm
2
Pixel configuration
1R1G1B/SMD2121 Black lamp
3
Pixel density
62500dots/sqm
4
Brightness
≥1200cd/sqm
5
Module size(W*H)
256mm×128mm
6
Module Resolution (W*H)
64 dots x 32dots
7
Module weight
200g
8
Cabinet size (W*H)
512mm×512mm
9
Drive IC
MBI5124
10
Drive mode
1/16 scan
11
Viewing Angle(V/H)
140 ºC
12
Grey Scale
65536 degree
13
Life time
>100,000 Hours (80%)
14
MTBF
>50,000 Hours
15
Operating Voltage
AC110V/220V±10%
17
Screen Power Consumption
Max: 750w/sqm; Average:250w/sqm
18
Input Power Frequency
50/60Hz
19
Operating temperature
-30--60ºC
20
Humidity
10%-95%
21
Refresh Rate
≥1920HZ
22
Control Method
Synchronized with computer monitor
23
Color Temperature
6500K-9500K
24
LED control system
LINSN,Nova-star,Colorlight is selectable
25
Control Distance
100 m (no repeating); Optical fiber transmission: 500m- 15km
Windows Xp / Windows 7 / windows 8 /8.1 / windows 10
TEL:+86 18923415589
Professional production: Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen
Company descripition: HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress. Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC. We are fully certified by ISO standards.
SHENZHEN HONGKINGLED OPTOELECTRONIC Co., Ltd, is one manufactuiers in SHENZHEN China, we product all kinds of full color indoor outdoor LED display, single color LED display, Di-color LED display,
SHENZHEN HONGKINGLED Display-your one stop solution provider for all things LED related. As a renowned manufacturer in the growing Chinese industry, we have completed more than 1000 worldwide installation projects In the pursuit of excellence, we succeeded in breaking numerous industry records. HONGKINGLED is widely acknowledged as a world-leading designer and producer of high quality LED screens. Our target markets include sports, advertising, rental & stage, etc. To learn more, please ask us about our fully featured customization options!
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress.
Development of overseas markets. Our success can largely be attributed to an outstanding reputation and a diverse client base.
Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC. We are fully certified by ISO standards.
