North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension:
2300X1000X1650 mm
Motor Power:
11 Kw
Max Pressure:
25 MPa
Length Of Blade:
600 mm
Nominal Pressure:
1250 Kn (125 Ton)
Work Efficiency:
12-25 Cuts/Minute
Max. Opening:
320 mm
Max. Shearing:
30X250 mm (Steel Plate Q235)
Operation Mode:
Auto/Manual
Color:
as You Request
Application:
Machinery & Hardware, Recycling
Type For Cutting Machine:
Hydraulic Cutting Machine
Type For Fold-bending Machine:
Hydraulic Fold-bend Machine
Type For Pipe And Tube Bending Machine:
Horizontal Hydraulic Pipe Bender
Product Description
Good quality High efficiency Reasonable price
Alligator Cutter Hydraulic ShearMachine Please contact our sales manager for more details & a customized solution!
1. Product Name Q08-125 Hydraulic Shear Machine Q08-125 Series: Hydraulic Metal Aluminium Shear Machine for Recycling Q08-125-600 Hydraulic Alligator Shear Machine (600 means 600 mm blade length)
2. Application The new design integrated mechanical, electrical and hydraulic system together, used to cut different sized metal tube and pipe materials
3. Customers and Expos We have had over 160 oversea customers from over 20 countries since 1997. Our products are soldwell all over China (including Taiwan area) and to more than twenty foreign countries, such as Canada, Russia, India, Indonesia,Malaysia, South Africa, Ukraine, Iran, Pakistan, Kazakhstan, etc. We have been to 6 countries' expos including 3 continents. 4. Product Demonstration 5. Qualifications(ISO9001,SGS ,TUV,Patents&Honors) We have got ISO9001 ,SGS ,TUV certificate and over 13 national patents and are getting more now. We have over 8 honors from different communities and associations 6. Features Hydraulic Acceleration System: Original & unique hydrauylic acceleration system without increasing the power of motor or oil displacement. The movement speed of mouth opening doubled. Integrated Design: parts are integrated to one frame, free of installation and commission, prolong the lifetime of machine and also convenient for transportation. Large Open Mouth: The new design mouth allows to cut larger materials, increase the scope of use. STD Sealing Parts: by using STD sealing parts, the lifetime and working stability has been increased obviously.
7. Pack & Transportation We have freight forwarder as good cooperation partner; we also have the export trading permission to reduce costs and save your valuable time. We offer woodcase or plastic wrapping to keep machine safe.
8. Custom Service We provide Services to translate Operation Manuel and Other Documents into your language, worry-free to operate and maintain 7x24 Technical Phone Service, we do care your real problems anytime Engineers available to service machinery overseas We have continues record for our customs with details to provide faster and more efficient custom service
9. Sales Experience We have many years sales experiences; we accept various payment methods for your convenience. Multiple protection methods are applied to the machine in order to lower potential risks during delivery process, we are trying to make our service better to make sure every set of machine is delivered perfectly.
Nominal pressure
KN
1250
125
inner diameter of main cylinder
mm
Φ 145
piston diameter
mm
Φ 90
stroke
mm
290
max.pressure
Mpa
25
motor
1set
11KW
pump
1set
63YCY14-1B
With an floor area of 30, 000 m2, workshop area of 12, 000 m2 and more than 80 sets of metal finishing machine and standard machine, Jiangyin Metallurgy Hydraulic Machinery Factory is a professional manufacturer of hydraulic machinery whose annual output of various equipments is more than 1, 000 sets with the sale up to hundred million yuan. We have accumulated rich experience and technology in a 25-year history of production, and the performance of our products has been in a leading position in the industry. We have been in this industry for about 25 years and we have 15 patents for our products.
Our products are sold well all over China (including Taiwan area) and to more than twenty foreign countries, such as Canada, Russia, India, Indonesia, Malaysia, South Africa, Ukraine, Iran, Pakistan, Kazakhstan, etc. Our factory is good at independent design and capable of producing various kinds of non-standard hydraulic machinery within 3, 000 tons. The products cover dozens of industries, such as iron and steel smelting, casting, machine parts manufacturing, fire equipment, textile and waste material recycling industry and so on. We have conquered the technical production problems of dozens of domestic enterprises by filling up many domestic blanks and customizing non-standard equipments for them. Now there are more than150 employees with 17 professional technicians in our factory, and through maintaining a long-term cooperation relationships with experienced experts, we support and develop hydraulic machinery for customers in various areas to help them save costs by increasing production efficiency and improving labor intensity.
Our main products including three series of hydraulic pressure depose metal process equipment(metal baler, hydraulic briquetting press, metal shearing machine), hydraulic pressure non-metal packer, whole set equipment for small steel cylinder etc., total more than 50 categories.
