Pipe Cutter:
Used in Workshop to Process Elbow, Tee and Cross T
Certification:
SGS
Automation:
Automatic
Product Type:
PE Pipe
Computerized:
Computerized
Product Description
Working Range: 100mm--1600mm
Application & Feature
It was designed to be used in workshop to process elbow, tee and cross
these fittings, according to setting angle and length to cut pipe.
Cut pipe in any angle from 0-45° , can expand to 67.5° .
Automatic check band saw broken and stop machine to ensure
operatore's safety.
Strong construction, easy operation, stable performance and low noise.
Model No.
DQJ 450S
DQJ 630S
DQJ 630
Cutting range (mm)
100-450
160-630
160-630
Cutting angle
0-45°(67.5°)
0-67.5°
0-45°(67.5°)
Angle tolerance
≤1°
≤1°
≤±1°
Cutting speed
334m/min
334m/min
≤200m/min
Forward way
Manual
Manual
Adjustable
Max working pressure
6.3MPa
Total power
0.75KW
1.5KW
3.7KW
Power supply
380V/50HZ
380V/50HZ
380V/50HZ
Total weight
186kg
1450kg
1900kg
Dimension(mm)
1520×1200×1730
4350×3460×2600
3133×2800×3430
Model No.
DQJ 800
DQJ1200
DQJ1600
Cutting range (mm)
315-800
450-1200
630-1600
Cutting angle
0-45°(67.5°)
0-45°(67.5°)
0-67.5°
Angle tolerance
≤±1°
≤±1°
≤±1°
Cutting speed
≤200m/min
≤250m/min
≤240m/min
Forward way
Adjustable
Adjustable
Adjustable
Max working pressure
6.3MPa
6.3MPa
6.3MPa
Total power
3.7KW
7KW
12KW
Power supply
380V/50HZ
380V/50HZ
380V/50HZ
Total weight
2300kg
4000kg
5600kg
Dimension(mm)
3530×2950×2650
4100×3600×3800
8350×7500×4827
