Free Dies Custom-Made Cable Crimping Tool

Free Dies Custom-Made Cable Crimping Tool
Price: US $ 1350-1550set
Min Order: 1set
Pay Type: L/C,T/T,Western Union
Prod Model: MT-51WS-2
Crimping Range: 6~51 mm (1/4~2")
Quantity Of Dies: 10 Sets
Accuracy: 0.01 mm
System Pressure: 31.5 MPa
Motor Power: 3 Kw / 4 Kw 1 2 3 Phase (Optional)
Voltage: 220 V ~ 415 V 50/60 Hz (Optional)
Output Volume Of Pump: 2.5 L / 5 L / 10 L (Optional)
Crimping Force: 500 T
Efficiency: 200 PCS/H
Weight: 260 Kg

Product Description

Free Dies Custom-made Cable Crimping Tool

1.Brief introduction of product:
Crimping machine is a kind of hydraulic device which is used to withhold pipes & fittings. It could connect metal joints with the fitting hoses firmly, such as high pressure oil hose, brake pipes on cars, motor oil hose, AC hose, dynamic hose, etc. It could be used in extensive field, such as engineering machinery, vehicles, hydraulic machinery, welding and cutting equipment.



2.Product advantage:
1) Die Base: Chromium 12 material
2) Electric Cabinet: Low failure rate, Humanized circuit (CKT) design
3) Dies: Chromium 12 material, Low wear rate, No dies deformation
4) Hydraulic Valve: Domestic first-line brand, Low failure rate, Good performance
5) Oil Pump: Axial piston pump, High pressure, Low failure rate
6) Cylinder: High density carbon steel, Large diameter, Strong crimping force

3.Configuration Table
Crimping range6~51mm ( 1/4~2" )
Quantity of dies10 sets
Item No. of dies15.19.23.26.31.36.41.47.55.60
Accuracy0.01 mm
Output volume of pump2.5 L / 5 L / 10 L (optional)
System pressure26 MPa / 31.5 MPa (optional)
Motor power3 kW / 4 kW  1 2 3 phase (optional)
Voltage220 V ~ 415 V  50/60 Hz (optional)
Crimping force500 T
Efficiency200 pcs/h
Maximum open diameter114 mm
The max open tolerance± 30 mm
Machine dimension720*550*810 mm
Package dimension790*600*940 mm
Net weight245 kg
Gross weight260 kg

4.Crimping parameter reference
Inner Diameter of the hoseDies No.Layer of the wireBefore crimpingAfter crimping Inner Diameter of the hoseDies No.Layer of the wireBefore crimpingAfter crimping
φ615Iφ19φ17 φ2231Iφ40φ37
15IIφ21φ18 31IIφ41φ37.5
15IIIφ23φ20 36IIIφ43φ39.5
15IVφ23φ20 36IVφ44φ40
φ815Iφ23φ19.5 φ2536Iφ43φ39.5
19IIφ24φ20.5 36IIφ44φ40.5
19IIIφ25φ22 36IIIφ46φ42
19IVφ25φ22 36IVφ47φ43
φ1019Iφ23φ20 φ3241Iφ50φ46
19IIφ25φ22.5 41IIφ51φ47
23IIIφ27φ24 47IIIφ55φ50
23IVφ28φ24.5 47IVφ56φ52
φ1323Iφ29φ26 φ3847Iφ53φ50
23IIφ31φ27.5 47IIφ55φ51.5
26IIIφ33φ29.5 47IIIφ60φ56
26IVφ34φ30 55IVφ63φ59
φ1626Iφ31φ28 φ4555Iφ63φ59
26IIφ34φ30.5 55IIφ65φ61
31IIIφ36φ32 63IIIφ66φ61.5
31IVφ36φ32.5 63IVφ68φ64
φ1931Iφ35φ32 φ5163Iφ68φ65
31IIφ37φ34 63IIφ70φ67
31IIIφ40φ36.5 63IIIφ74φ70
31IVφ41φ37 63IVφ75φ71

5.Impression drawing of crimping


6.Preparatory work before installation
1) Prepare 65L BP46# hydraulic oil in winter and BP68# in summer.
2) Prepare a 6mm cable to connect the machine and the general switch.

7.The procedure of setup operation and notice
1) In order to increase the lifetime of the crimping machine, and reduce the malfunction happens, please fuel the original BP46# hydraulic oil, or it will cause the problems of the reversal valve.
2) The electric cabinet must be opened and checked by skilled electricians. It will be easily for you to take the electric cabinet off by loosing the four screws when you plan to check it.
3) The rusted fitting and steel pipe can not be used. Warning, it will be dangerous if you have some impurity in Nose such as iron scrap , mud and sand, cotton and silk and so on. The slope between the mould seat and front board must be cleaned frequently.
4) Lubricate the front internal cone by little oil brush or oil squirt before using. (The butter and hydraulic oil mixed by 1:1). One or more times according to the workload.
5) Please put the work-piece into the mould when you plan to deal with it. Warning, do not let it out of the mould, or the mould will be destroyed .
6) In case of destroying or breaking off the mould , please do not use the mould out of the range.
7) Please take good care of your hands when operating the machine.
8) In order to avoid the Spring transforming, the mould base must be back to the original place when the crimping machine power off.
9) To avoid reducing the service life time of the machine, please turn off the general power switch after work.

8.Company Profile
We are the professional manufacturer with 8 years experience in production of varies of hydraulic equipments. Our main products are Hose Crimping/Cutting/Skiving Machines. Besides, high pressure steel wire hose, low pressure hose, hydraulic fittings, rubber accessories, etc.
Widely used in industries of engineering machinery, agricultural machine, construction field, oil field, steel, shipbuilding, coal mine, etc.
Enterprise tenet: Quality first, integrity based, service paramount, forge ahead
Development: Scientific management, innovation and enterprising
Market: Super quality and competitive price, Keep up with the times
Service: Customer first, sincere and timely
Cooperation: Integrity based, mutual benefit and win-win



9.Package details


FAQ:
Why choose us?
1) More than 10 years of production experience
2) Timely after-sales service
3) A wide range of products to meet all customer needs
4) No middlemen to make price difference in direct sales
5) Short delivery time, within 3~7 days
6) Support Alibaba Trade Assurance protection
What can we offer?
1) Affordable first price
2) Quality assurance, certificate of origin, no fakes
3) OEM and ODM support
What products our machine can crimp?
Hose, excavator oil hose, construction machinery oil hose, coal mine hose, air conditioning hose, PTFE hose, resin hose, wire guide pipe, air spring, bath pipe, steel wire rope, building steel pipe, stainless steel pipe, etc.

9.Welcome to contact us and talk more details!


Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.

Ping Li, general manager of our factory, proficient in a variety of buckle machine performance characteristics, with strong professional and technical capacity.

Our factory delivery efficiency is high, single order, the day can be packaged factory, more than 15 days to purchase packaging factory shipment.

Support OEM or OMD, each machine before delivery performance testing, quality control to strictly.

I plant with more than 10 years of design and production experience, support bulk custom products, large concessions.

Our factory to sell each of the machines, are provided after-sales maintenance services, professional after-sales team to keep in touch with you in real time.

Various configurations are available, If you are interested, come and talk to us!

Welcome customers to our factory to visit the guide, understand our company's products.
