Prod Model: |
BLD-400 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Brand: |
Bld |
Model Produced: |
Bld-400, Bld-0041 |
Max Steel Bar Diameter Can Tie: |
40mm, 68mm |
Quality Similar As: |
Rb397/395/392, Rb655/650/650A Rebar Tier |
Fitting Tie Wire: |
Tw897A, Tw1525 Tie Wire |
The Packing: |
Carton and Pallet |
Sample: |
Available and Fast Delivery |
Handle Material: |
Plastic |
Type: |
Rebar Tying Machine |
Product Description
Automatic rebar tying machine or is called Rebar tier or rebar tier guns, is one new intellectualized construction power tools.
It ties the rebar automaticly instead of the traditional tying method by hands, it will increase the working efficiency by 3-4 times. The rebar tying machine can be widely used in many construction industry such like building site, bridge, subway and so on.
1. Advantage:
it is used for building market , including civil building, floor pipe, heating floor mesh,steel bar,etc.
it can save 3-5 times time than manpower by hand.
2. Detailed informations:
Model No. | BLD-200 | BLD-400 | BLD-510 |
Max Tying Diameter | 21mm | 40mm | 50mm |
Time of Making a Knot | 0.8 seconds | 0.8 seconds | 1.0 seconds |
Voltage | DC9.6V | DC9.6V | DC9.6V |
Weight | 2.15kgs | 2.2kgs | 2.25KGS |
Turns per Tie | 2 turns/3turns | 2turns/3turns | 3turns/4turns |
Ties per Coil | Approx. 230ties(2turns) | Approx.160ties(2turns) | Approx. 100 ties(3 turns) |
Ties per Charge | 4-5 Coils | 6-7 Coils | 7-8 Coils |
Length of Wire for Tying | 380mm/2 turns 510mm/3 turns | 600mm/2 turns 780mm/3 turns | 1100mm/3turns 1350mm/4turns |
Dimension(L)X(W)X(H) | 398mmX150mmX410mm | 398mmX150mmX410mm | 398mmX150mmX410mm |
Feature of rebar tying machine
1,lightweight and compact body
2,reduces tying time
3,NI-MH higher capacity battery
4,reduces risk of health problems
5,brushless twisting
6,one hand operation
Contents of the tool box: 1 rebar tying machine
2 battery pack
1 quick charger
4 galvanized wire roll
1 long nose plier
1 instruction manual
1 hex wrench
BLD-400 rebar tying machine dedicated rebar tie wire: TW897A rebar tie wire
One carton of TW897A rebar tie wire for RB397/395/392 rebar tying machine
Includes: 50 coils per carton, 50 cartons per pallet
Weight of one carton: 44 lbs.
BLD-0041 rebar tying machine dedicated rebar tie wire: TW1525 rebar tie wire
Rebar Tie Wire for RB650, RB650A, RB655, BLD-0041 and other similar rebar tying machine
Material: galvanzied, annealed, pvc coated wire
Diameter: 1.57mm
Length: 28m
Packing: 50 coils/carton, 50 cartons/pallet
MOQ: 1 pallet
rebar tying machine and TW897A, TW1525 quality rebar tie wire supplier
