Prod Model: |
DCB80 |
Piling Diameter: |
300-800mm |
Type: |
Diesel Hammer |
Product Description
Pile driving, Pile Driver, Pile Hammer,diesel pile hammer,Diesel hammer,pile driving hammers,
construction piling, pile drivers, hammer pile, foundation pile Diesel hammer pile driver can put up guider rod type, drum-type diesel hammer, pipe piles, square piles with all kinds of precast pile specification sizes.
1. The leader is made of manganese plates with two pieces and curving where it jointing two welding lines. Meanwhile, the inside leader jointing four reinforcing ribs to enhance the structure.
2. All of the hydraulic operation, monitor instrument are controlled in driver's cab. And walking, landing leg and the lifting leader are controlled by cylinder. This machine is more stable performance and easy to operate.
3. There is strong integrity of folding leader, assembled chassis, convenient discharging in addtion to be less time, less labor effort and reliable.
Model No. | DCB60-15 | DCB80-18 | DCB100-20 |
Hammer type | DD63/TD50 | DD83/TD62 | DD103 |
Piling diameter(mm) | 300-600 | 300-800 | 300-800 |
Piling depthr(mm) | 15 | 18 | 20 |
Main winch pulling force(T) | 5 | 8 | 10 |
Vice winch pulling force(T) | 3 | 3 | 5 |
Power(KVA) | 100 | 100 | 100 |
Working Gradeability | 2° | 2° | 2° |
Travelling motion | foot-step | foot-step | foot-step |
Working condition(m) | 13x5.3x25 | 13x5.3x25 | 13x5.3x25 |
Transportation condition(m) | 15.8x2.5x3.38 | 15.8x2.5x3.38 | 15.8x2.5x3.38 |
Overall weight(T) | 37 | 45 | 55 |
Xuzhou Hercules Machine Manufacture Co., Ltd. is ISO9001 quality management system certification enterprise, the certified supplier by SGS, the high-tech private enterprise in Jiangsu province, Jiangsu province AAA grade Credit enterprise; Jiangsu province AAA grade Quality, Integrity Services enterprise and the company also was "Xuzhou Piling Machinery (Hercules) Engineering Research Centers".
Hercules piling machinery was awarded the title of Jiangsu High-tech Products. Our company has 20 state grade patents and new practical patents. Our machine had become the new benchmark for quality piling machinery!
Our main products include Long Auger Drilling Rigs (drilling diameter: Φ 300-Φ 1500mm, drilling Depth: 10m-35m), Diesel Hammer Pile Drivers (4T-10T), Rail Type and Electric Crawler Wick Drain Drivers, Percussion Drilling Rigs (drilling diameter: Φ 800-Φ 3000mm). Especially the machine Multi-function Pile Drivers integrated with expansion pile, compaction pile, gravel pile, pilling rig and prefabricated pipe pile, which favored by the users and lead the sale. We can also make the machinery and the components according to the customers' Requirement.
With the characters of first-class R & D team, controlling the overall design, pursuit of the details, continuously improving according to the users' Experience and lesson in practical engineering, especially the strengthening processing for the key parts, our machines ensure to afford higher-intensity operations and meet user higher efficient construction requirements.
Hercules always believes that the interests of customers are more than our own interests which is also the standard for you to trust us. Hercules treasures your trust and confidence and we always begin from maintaining your construction efficiency.
