Equipment Recommend:
Pellegrini, Gaspari, Barsanti, Breton, Simec
Reinforcement:
Plastic and Steel Cable
Beads Diameter:
6.3mm/7.3mm or 8.4mm
Type Of Beads:
Sintered or Free Sintering
Beads Per Meter:
33/ 35/36/37bpm
Cutting Speed:
15-80cm/Hour Down Speed
Cutting Life Time:
8-20m2/Lm
Linear Speed Recommended:
24-30m/S
Product Description
Description Diamond Wire Saw for working on multi-wire block cutting machines from Pellegrini, Gaspari, Barsanti, Pedrini, Cofilast, Breton, BM, Simec and Nodosafer etc:
With diamond wire to cut blocks is a technique revolution for block cutting. It is 10-15 times more effective than traditional gang saw cutting, also it can cut stones with different hardness. The power cost is much lower than gang saw. Wire saw cutting makes lower noise and the water demand is low, and it can be recycle d. it makes small amount of stone powder, and easy to be cleaned and recycled. The machines do not take much space either. Technical Data KEENTOOL Diamond Wire Saw for Multi-Wire Block Cutting Machine:
APPLICATIONS
Art No
Specification (mm)
Beads/M
Reinforcement
To be used on multi-wire machines for cutting granite slabs
ROC-MW73P
¢7.4×7.0
37
Plastic
ROC-MW80P
¢8.0×6.0
37
Plastic
ROC-MW90P
¢8.0×6.0
37
Plastic
Cutting Material
Linear Speed (M/S)
Down Speed (CM/H)
Cutting Life (M2/M)
Soft Granite
24-30
50-80
12-14
Medium Granite
22-28
40-60
10-12
Hard Granite
22-28
30-50
7-10
Abrasive Granite
24-30
50-80
10-12
SPECIFICATION OF BEADS
Out Diameter
Length of work layer (mm)
Bead Length
Manufacture Tech
¢7.4
7.0
11
Sintered
¢8.0
6.0
11
Sintered
¢9.0
6.0
11
Sintered
With multi diamond wire to cut slabs is a technique revolution for block cutting, with great advantages as below:
Multi diamond wire is 10-15 times more effective than traditional gang saw cutting,
Multi wire can cut stones with different hardness.
The power cost is much lower than gang saw.
Wire saw cutting makes lower noise
The water demand for cutting is low, and it can be recycled.
Multi wire cut makes small amount of stone powder, and easy to be cleaned and recycled.
The multi wire machines do not take up much space for installation and work
Keentool Multi Diamond Wire with Features as below:
Keentool studies the granite to be cut to design the best bond, number of beads per meter;
Keentool wires use the top quality steel cable from Germany or Italy
KEENTOOL wires use the Bayer or BASF plastic grains from Germany, and the most advanced plastic injection equipment and system to make sure our diamond wire can work with stable performance till the end
Packaging & Shipping: Packaging: Carton with water proof plastic. Delivery time: In 15 days for 1000meters
Our Services: 1. Diamond Wire Cutting Operation Training and Guidance 2. Full Consulting Service and Turnkey Solutions for the Stone Quarry
Always at your service!
Quanzhou Keen Diamond Tool Co., Ltd is one of the leading manufacturer of series machinery and diamond tools for natural stone quarry, processing and civil construction work, which has very good presentation in Europe, North&South America, Southern Africa, Middle East and Asian.
We are committed to professional total solution and package supply for natural stone quarry and controlled demolition of civil construction:
1. For stone Quarry:
Package supply of quarry machinery and consumables for quarries of granite, marble, sandstone, limestone, travertine and slate, such as Wire saw machine, DTH Drill, block trimming wire saw, diamond wire, generators and air compressors etc.
Consultant service for project evaluation, quarry development and mining construction
Consultant and marketing service for block distribution
2. For stone Factory:
Total solution and package supply of machinery and diamond tools for stone cutting, profiling, drilling and polishing, such as block cutting machine, bridge circular saw machine, bridge eage cutting machine, static stationary wire saw machine; Diamodn wire, diamond blade, diamond segments, diamond core drill, diamond fickert, diamond cup wheels and diamond polishing tools etc.
3. For civil construction:
Total solution and consult service for wire cutting of civil construction like old buildings, bridge, dams, highway, rail way, steel structure and underwater cutting of kinds of pipes.
Package supply of machinery, diamond wire and other consumables for wire cutting of civil construction
Diamond blade for cutting concrete, reinforced concrete and asphalt
Diamond Core Drills for concrete reinforced concrete, wall and asphalt
Diamond polisher for polishing of concrete floor, wall and blocks
The core values of our company is to create value for customers, provide opportunities for staff and make benefits for the society. Our principle for business is customer-oriented and quality first. Keen looks forward to cooperating with you.
