Inlet And Outlet Size:
100(4")
Rated Speed (HP/Rpm):
3, 6
Displacement (M3/H):
90
Pump Lift (M):
30
Suction Height (M):
7
Engine Mddel:
Zh270
Displacement (Ml):
269
Engine Max Output (HP/Rpm):
9.0/3600
Fuel Volume (L):
6
Bore X Stroke:
77*58
Material:
Cast Iron
Structure:
Single-stage Pump
Power:
Electric
Application:
Chemical Pump
Theory:
Centrifugal Pump
Type:
Water Pump
Product Description
9 HP engine makes this pump quiet, powerful and dependable!
Pumps up to 22, 895 GPH. Silicon carbide mechanical seal lasts many times longer than ceramic seals because it's far more resistant to corrosion, wear and heat.
4in. Inlet and outlet. Includes FREE wrench and strainer.
Generator
Inlet and outlet size:
100 (4")
Rated speed (HP/rpm):
3,600rpm
Displacement(m3/h ):
90
Pump lift (m):
30m
Suction height (m):
7m
Engine model:
ZH270
Displacement:
269ml
Engine max output: Hp/rpm:
9.0/3600
Fuel volume (L):
6L
Bore x stroke:
77x58
Compression ratio:
8.5:1
Engine
Oil volume (L):
1.1L
Min fuel consumption g/HP-hour:
313g/HP-hour
Ignition model:
transistor magneto
Start mode:
recoil
NW/GW (kg):
47/49
Dimension
Package dimensions (mm):
650 x 510 x 555
Taizhou Genour Power Machinery Co., Ltd was established in 2003, is the leading manufacturer, exporter of quality products in the engine, generator and water pump business. Employing over 300 staff, and high intermediate technical personnel accounts for above 20%. Taizhou Genour has its Head Office in Fenxi Industrial area, Duqiao Town, Taizhou city, Zhejiang. Factory building area covers about 20, 000 square meters. It is capable to produce 200, 000 sets a year.
Manufacturing includes, gasoline engine, gasoline generator, gasoline water pumps, gasoline concrete vibrator, gasoline generator with welding, diesel engine, diesel generator, diesel water pump, pressure washer and so on. Our sales network covers Europe, East Europe, South America, Southeast Asia, Africa and Middle East area etc., our products are exported to more than 65 countries.
We pay much more attention to the quality of products, and has been certified by ISO9000 and ISO 14000. Each step of manufacture is carried out with strict adherence to the standards of these certifications. While many products have gotten CE, EMC, NOISE, GS, SONCAP and EPA certifications to constantly bring our customers reliable and high-quality products. You can count on us for quick and economical after-sale service solutions due to our well-trained worldwide dealer network. It is always our goal to develop our brand recognition based on exceptional customer service, and to be a contributing member to our employees and the communities in which we do business, both economically and socially!
We are looking forward to going hand in hand with you and co-create resplendence.
