Welded Wire Mesh (HP-001)

Welded Wire Mesh (HP-001)
Price: US $ 13-15/Roll
Trade Terms: FOB,CFR,CIF
Min Order: 100/Roll
Pay Type: L/C,T/T
We manufacture and exporter galvanized welded wire mesh
Type of welded wire mesh: Galvanized welded wire mesh(include galvanized before welding and galvanized after welding), hot-dipped galvanized welded wire mesh, electro galvanized welded wire mesh, PVC-coated welded wire mesh, stainless steel wire mesh
Hole size of welded wire mesh: 1/4" to 200mm
Wire diameter of welded wire mesh from 0.5mm to 6.0mm
Width and length of welded wire mesh according to your requirement
Packing of welded wire mesh: In roll, in sheet



Specification List of Welded Wire Mesh

Opening

Wire Diameter

In inch

In metric unit(mm)

1/4" x 1/4"

6.4mm x 6.4mm

22,23,24

3/8" x 3/8"

10.6mm x 10.6mm

19,20,21,22

1/2" x 1/2"

12.7mm x 12.7mm

16,17,18,19,20,21,22,23

5/8" x 5/8"

16mm x 16mm

18,19,20,21,

3/4" x 3/4"

19.1mm x 19.1mm

16,17,18,19,20,21

1" x 1/2"

25.4mm x 12.7mm

16,17,18,19,20,21

1-1/2" x 1-1/2"

38mm x 38mm

14,15,16,17,18,19

1" x 2"

25.4mm x 50.8mm

14,15,16

2" x 2"

50.8mm x 50.8mm

12,13,14,15,16

Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.8m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request.


Galvanized Fencing Mesh

Opening

Wire Diameter

In inch

In metric unit(mm)

2" x 3"

50mm x 75mm

2.0mm,2.5mm,1.65mm

3" x 3"

75mm x 75mm

2.67mm,2.41mm,2.11mm,1.83mm,1.65mm

2" x 4"

50mm x 100mm

2.11mm,2.5mm

4" x 4"

100mm x 100mm

2.0mm,2.5mm

Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.8m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request.


PVC Coated Welded Mesh

Opening

Wire Diameter

In inch

In metric unit(mm)

1/2" x 1/2"

12.7mm x 12.7mm

16,17,18,19,20,21

3/4" x 3/4"

19mm x 19mm

16,17,18,19,20,21

1" x 1"

25.4mm x 25.4mm

15,16,17,18,19,20

Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.2m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request.

















Prod Model: CT-WDM
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Welded Wire Mesh Surface Dealing: Nature Color, Galvanized or PVC-Coated
Hole Size: From 1/4" to 200mm
Wire Diameter: 0.45mm to 4.0mm
Material: Low-Carbon Iron Wire
Hole Shape: Square
Surface Treatment: Galvanized
Application: Construction Wire Mesh
Color: Green
Type: Welded Mesh
Certification: ISO9001
Condition: New
Mesh Size: 1/4" to 3"
Weave Technique: Welded
Our factory is situated in Anping County which has long been known as Homeland of Wire Mesh in China, Started since 1989, this factory has rich experience in iron wire and wire mesh.

Our production:

Wire system: Black annealed wire, galvanized wire, including coil wire, spool wire, and U type tie wire, cutting wire, wire sack ties and so on.

Wire mesh system: Welded wire mesh, hexagonal wire mesh, black woven cloth, stainless steel wire mesh, brass wire mesh and perforated metal, expanded metal, plastic wire mesh.

At present, we have been exporting to more than 80 countries, for example, USA, Canada, Uruguay, Brazil, Agentina, New Zealand, Kuwait, Pakistan, Singapore, Japan, the Netherlands, and so on

We have win high repulation by the high quality and quick delivery, and expanded ten times large export amount compare 10 years before.

We would like to win your long term businss by our high quality products and competitive price.
