WC67 hydraulic power press brake new congdition China export
| Price: |
US $ 9800/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
WC67 bending machine,hydraulic power,new congdition,china exportStandard Facilities: 1. ESTUN E21 NC control + Frequency inverter 2.Front support arms3. Motorized stroke adjustment 4. T slot on both front side and back side of the worktable5. OMAGE Hydraulic valve6. SUNNY hydraulic pump 7. Siemens famous brand motor 8. Siemens or Schneider Electric parts9. Machine power is turn-off when the electric cabinet door opened 10. Upper clamps with Anti Wedges 11. Hydraulic and Electrical overload protection12. Side safety guard and Full height back safety guard13. With standard Top punch and Bottom Die14. Back gauge beam is made of profile steel and liner guide15. Back gauge is supported with ball screw and polished steel round bar with 0,05mm accuracy2. Estun E21 NC Press Brake Control system:1. Monochrome LCD Box Panel.2. Integral factor programmable freely3. Automatic positioning control5.Internal time relay6.Ram stroke counter3. Our Services1: Response in time after getting customer's claim1: Provide solution in 1 day2: Usually solve problem within 2 days2. For big machine, Installation Service is available as per customer's requirement4. Training ServiceOur technician is available to your factory and offer training of how to use our machines. As well, you may send your technician to our company to learn how to operate machines.5. Quality GuaranteeWe guarantee the quality of machine (e.g. processing speed and working performance is the same as the data of samples making). We sign the agreement with detailed technical data.We arrange final test before shipment. We run the machine for a few days, and then use customer's materials for test. After making sure machine is the best performance, then make shipments.6. Main features1. The whole machine is in sheet plate welded structure, which internal stress eliminated by vibration aging technology, high strength and good rigidity of machine.2. Double hydraulic oil cylinder is applied for upper transmission, provided with mechanical limit stopper and synchronous torsion bar, stable and reliable operation, as well as high precision.3. Electrical adjustment and manual fine-tuning adjustment mode are adopted for distance of rear stopper and stroke of gliding block, and fitted with digital display device, easy and quick in use.4. Upper clamp is fitted with compensation device. 5. Worktable mechanical compensation or hydraulic compensation device is optional. Main Specification:| model | Normal pressure(kn) | Working table length (mm) | Distance between housing | Throat depth (mm) | RAM travel (mm) | Max. open height | Adjust- ment of RAM travel (mm) | Working table Height (mm) | Main motor | speed | Oil flow rate (L/min) | Machine overall Dimension (mm) L x W x H | Machine weight(T) |
| Power (kw) | Speed (mm/s) | Approach/ Working/ return |
| 30X1300 | 300 | 1300 | 1110 | 200 | 40 | 275 | 80 | 710 | 3 | 1440 | 8 / 6 / 8 | 10 | 1800X1550X1900 | 1.8 |
| 30X1600 | 300 | 1600 | 1225 | 200 | 40 | 275 | 80 | 710 | 3 | 1440 | 8 / 6 / 8 | 10 | 1950X1550X1900 | 2.1 |
| 40X1300 | 400 | 1300 | 1080 | 200 | 100 | 275 | 80 | 710 | 4 | 1440 | 8 / 6 / 8 | 10 | 1950X1550X1990 | 2.1 |
| 40X1600 | 400 | 1600 | 1200 | 200 | 100 | 320 | 80 | 710 | 4 | 1440 | 8 / 6 / 8 | 10 | 1950X1550X1900 | 2.3 |
| 40X2000 | 400 | 2000 | 1500 | 220 | 100 | 320 | 80 | 730 | 4 | 1440 | 8 / 6 / 8 | 10 | 2150X1600X1980 | 2.8 |
| 40X2200 | 400 | 2200 | 1500 | 220 | 100 | 320 | 80 | 740 | 4 | 1440 | 8 / 6 / 8 | 10 | 2250X1700X1950 | 3 |
| 40X2500 | 400 | 2500 | 2000 | 220 | 100 | 320 | 80 | 730 | 4 | 1440 | 8 / 6 / 8 | 10 | 2505X1125X2000 | 3.1 |
| 50X2500 | 500 | 2500 | 1900 | 250 | 120 | 300 | 120 | 750 | 5.5 | 1440 | 8 / 6 / 8 | 10 | 2570X1270X1800 | 3.3 |
| 50X3200 | 500 | 3200 | 2600 | 250 | 120 | 300 | 120 | 750 | 5.5 | 1440 | 8 / 6 / 8 | 10 | 3270X1350X1960 | 3.2 |
| 63X2000 | 630 | 2000 | 1500 | 250 | 100 | 360 | 100 | 770 | 5.5 | 960 | 8 / 6 / 8 | 25 | 2060X1725X2280 | 3.8 |
| 63X2500 | 630 | 2500 | 2050 | 250 | 100 | 360 | 100 | 770 | 5.5 | 960 | 8 / 6 / 8 | 25 | 2560X1725X2280 | 4.2 |
| 63X3200 | 630 | 3200 | 2600 | 250 | 100 | 360 | 100 | 770 | 5.5 | 960 | 8 / 6 / 8 | 25 | 3260X1700X2260 | 5.5 |
| 80X3200 | 800 | 3200 | 2600 | 250 | 100 | 360 | 100 | 780 | 7.5 | 960 | 8 / 6 / 8 | 25 | 3520X1620X2230 | 6.6 |
| 80X4000 | 800 | 4000 | 3200 | 250 | 100 | 360 | 100 | 780 | 7.5 | 960 | 8 / 6 / 8 | 25 | 4050X1820X2280 | 7.5 |
| 100X2500 | 1000 | 2500 | 2050 | 320 | 130 | 390 | 100 | 850 | 7.5 | 960 | 8 / 6 / 8 | 25 | 2600X1750X2230 | 6.8 |
| 100X3200 | 1000 | 3200 | 2600 | 320 | 130 | 390 | 100 | 850 | 7.5 | 960 | 8 / 6 / 8 | 25 | 3500X1750X2230 | 7.2 |
| 100X4000 | 1000 | 4000 | 3200 | 320 | 130 | 390 | 100 | 850 | 7.5 | 960 | 8 / 6 / 8 | 25 | 4060X1800X2500 | 8.2 |
| 100X5000 | 1000 | 5000 | 4080 | 320 | 130 | 390 | 100 | 850 | 7.5 | 960 | 8 / 6 / 8 | 25 | 5100X1800X2700 | 9 |
| 125X2500 | 1250 | 2500 | 2050 | 320 | 130 | 390 | 100 | 850 | 11 | 960 | 8 / 6 / 8 | 25 | 2600X1750X2330 | 7.8 |
| 125X3200 | 1250 | 3200 | 2600 | 320 | 130 | 390 | 100 | 850 | 11 | 960 | 8 / 6 / 8 | 25 | 3500X1750X2330 | 7.5 |
| 125X4000 | 1250 | 4000 | 3200 | 320 | 130 | 390 | 100 | 850 | 11 | 960 | 8 / 6 / 8 | 25 | 4080X1750X2500 | 7.5 |
| 125X5000 | 1250 | 5000 | 4080 | 320 | 130 | 390 | 100 | 850 | 11 | 960 | 8 / 6 / 8 | 25 | 5080X1750X2600 | 7.5 |
| 160X3200 | 1600 | 3200 | 2600 | 320 | 200 | 470 | 160 | 840 | 11 | 960 | 7 / 5 / 7 | 25 | 3400X2100X2520 | 10.5 |
| 160X4000 | 1600 | 4000 | 3200 | 320 | 200 | 470 | 160 | 840 | 11 | 960 | 7 / 5 / 7 | 25 | 4060X2100X2600 | 11.8 |
| 160X5000 | 1600 | 5000 | 4080 | 320 | 200 | 470 | 160 | 840 | 11 | 960 | 7 / 5 / 7 | 25 | 5080X2100X2600 | 14 |
| 160X6000 | 1600 | 6000 | 4800 | 320 | 200 | 470 | 160 | 840 | 11 | 960 | 7 / 5 / 7 | 25 | 6100X2100X2680 | 15.8 |
| 200X3200 | 2000 | 3200 | 2600 | 320 | 200 | 520 | 180 | 850 | 15 | 960 | 7 / 5 / 7 | 63 | 3400X2200X2650 | 12.8 |
| 200X4000 | 2000 | 4000 | 3200 | 320 | 200 | 520 | 180 | 850 | 15 | 960 | 7 / 5 / 7 | 63 | 4080X2200X2650 | 14.5 |
| 200X5000 | 2000 | 5000 | 4080 | 320 | 200 | 520 | 180 | 850 | 15 | 960 | 7 / 5 / 7 | 63 | 5100X2200X2660 | 16 |
| 200X6000 | 2000 | 6000 | 4800 | 320 | 200 | 520 | 180 | 850 | 15 | 960 | 7 / 5 / 7 | 63 | 6120X2200X2660 | 17.5 |
| 250X3200 | 2500 | 3200 | 2600 | 400 | 250 | 560 | 220 | 865 | 18.5 | 960 | 7 / 5 / 7 | 63 | 3400X2300X2800 | 13.5 |
| 250X4000 | 2500 | 4000 | 3200 | 400 | 250 | 560 | 220 | 865 | 18.5 | 960 | 7 / 5 / 7 | 63 | 4120X2300X2800 | 15 |
| 250X5000 | 2500 | 5000 | 4080 | 400 | 250 | 560 | 220 | 865 | 18.5 | 960 | 7 / 5 / 7 | 63 | 5100X2300X2850 | 17 |
| 250X6000 | 2500 | 6000 | 4800 | 400 | 250 | 560 | 220 | 865 | 18.5 | 960 | 7 / 5 / 7 | 63 | 6120X2300X2900 | 19 |
| Prod Model: |
WC67Y-100/3200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Steel Body: |
Digital Readout E21 |
| Type For Fold-bending Machine: |
Hydraulic Fold-bend Machine |
| Rated Pressure: |
1000kn |
| Working Table Length: |
3200mm |
