Vinyl Label Cutting Machine, Vinyl Label Cutter (VCT-LCR)
| Price: |
US $ 2700-5400/Piece |
| Trade Terms: |
FOB,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Vinyl Label Cutting Machine, Vinyl Label Cutter (VCT-LCR)Features:1. It can be compatible with any roll to roll label printer.
2. It can realize contour cutting automatically with the assistance of red light positioning system. This system can sense the printed mark point to realize accurate cutting.
3.User-friendly designed operating software "label studio" can easily make file for printing and cutting by one step and help you save materials when massive production.
4. Label Studio software: designed by Australia DragonCut Company, combined the functions of making layout for printing and cutting. The distance between each label can be adjusted easily, avoiding material waste. You can use it make file in PDF to be printed on any roll to roll label printers.
5. It also can sense different media's light-reflection to adjust sense sensitivity by itself to upgrade the cutting precision.
6. With auto feeding system and waste-removal system, can realize label making automatically with high efficiency.
7. This machine is featured as fast and precise cutting for kinds of different labels, very suitable for small production.Application:Field: advertising industry, decoration industry, packing industry etc.
Material: stickers, glossy paper, PET, PP, PVC, PC, Wall Paper etc.Technical Parameters: | Machine Model | Label Cutter VCT-LCR |
| Max. media feeding size | 16" (406mm) |
| Max. cutting width | 12"(305mm) |
| Max. cutting length for one time | 6" (300mm) |
| Max. cutting straight-line speed | 37.8" /s (960mm/s) |
| Max. cutting curve-line speed | 23.6"/s (600mm/s) |
| Motor power | 25watt |
| Max. down force | 750g (3g/step) |
| CPU | 64 BIT DSP 32M Flash |
| Repeating precision | 0.082mm |
| Noise | 35 DB OR LESS |
| Software functions | 1) Automatic offset sensor;
2) automatic inductive value;
3) control identification mark. |
| Ambient temperature | 5 - 35 degrees |
| Support File Format | HPGL commands |
| Packing size | 38.6"x28"x18.1" (980x710x460mm) |
| G.W / N.W | 110/75kgs (154.3lb/121.3lb) |
| Compatible software | Label Studio from DragonCut |
| Packing size | 114*70*80cm |
Our Value and Obligation:1) Do business with integrity. No cheating and deception.
2) We are committed to offer high quality products.
3) We are committed to provide professional and efficient premium services.
4) If you are or will be a distributor, we are willing to help you develop new markets, enhance
performance.
5) If you are the end user, we will help you choose the right products and offer life-time technical support. Quality Control: 1) During procurement, we have strict control about the quality of the spare parts.
2) Manufacturing period, we have QC department to monitor each step of production process by different testing tools and inspection forms.
3) Before shipment, we will test machine by different common materials, and make necessary adjustment and data record. Also we will take photos and some sampling videos for customers. Warranty: 1) Two years warranty for the whole machine; Lifetime Maintenance.
2) Within warranty period, any damage happens due to machine quality problems; VICUT will be responsible for replacing parts for free, except regular consumables (such as cutting tools) and the damage by man-made irregular operating.
3) If any part damaged is not in warranty period, VICUT will repair it for free.
4) Customer has to pay the International Express cost.
5) Warranty time starts after goods arrival in customer's location.
After-sale Service:1. Guarantee long-term supply for spare parts; Unlimited Lifetime maintenance.
2. Offer life-time 24 hours online technical support for free. We can communicate by way of phone,
e-mail, whatsapp, wechat, QQ, skype, or team-view, etc.
3. Offer free training for operation & maintenance of equipment in our factory.
4. Offer On-Site paid service for machine installation and technical training. Customer need to pay visa application cost, air ticket cost, local hotel & food cost, and service cost is 80USD per day.
5. We will make return visit non-scheduled, in order to make assessment for after-sale service technician, make sure our service more and more better. Contact us:If you want to get more information, please feel free to contact us.
Contact person: Jason Guo
Contact number: 0086-15155376295
| Prod Model: |
VCT-LCR |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max Cutting Straight-Line Speed: |
960mm/S |
| Max Cutting Curve-Line Speed: |
600mm/S |
| Max Media: |
6" for One Time |
| Motor Power: |
25 Watt |
| Max Down Force: |
750g (3G /Step) |
| CPU: |
64 Bit DSP 32m Flash |
| Repeating Precision: |
0.082mm |
| Noise: |
35 dB or Less |
| Ambient Temperture: |
5-35 Degrees |
| Packing Size: |
114*70*80cm |
| Imprinting Type: |
Rotary |
| Placing Form Of Template: |
Horizontal |
| Die Cutting Tool: |
Steel Plate |
| Automatic Grade: |
Automatic |
| Application: |
Stickers Products |
