Radial Drilling Arm Machine with Hydraulic Power (Z3040*16/1)

Radial Drilling Arm Machine with Hydraulic Power (Z3040*16/1)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
Features
Heavy Duty Precision manufactured radial arm drilling machines
Hydraulic column & head clamp ensures fixed tool positioning
Oil-bath lubricated gearbox with hardened & ground gears
16 speed auto down-feed: 0.04 ~ 3.2 (mm/rev)
Unique hydraulic operated feed & spindle drive system
Arm height adjusted via vertical leadscrew & heavy duty induction motor
High quality fine grain cast iron with ribbing ensures extremely low vibration
Coolant pump system with flexible hose
Drill capacity 50mm
Work light mounted underneath arm providing direct light on work piece
Quiet and smooth operation
Includes
Coolant pump
Worklight & toolbox
Heavy Duty Tee-slotted box table
Safety chuck guard



Model
UnitsZ3050*16/1Z3040*16/1
Max drilling diametermm5040
Distance from spindle center to column surfacemm350-1600350-1600
Distance from spindle nose to base surfacemm350-1220350-1220
Spindle box travelmm12501250
Rotary angle of radial armdegree±180±180
Spindle taperMorse54
Spindle speed and stepsR/min25-2000  16steps25-2000  16steps
Feeding speed and stepsMm/r0.04-3.2  16steps0.04-3.2  16steps
Spindle travelmm315315
Main motorkw43
Net weightkg35003500
Working area of basemm1590*8401590*840
Working table areamm500*630500*630
Overall dimension(L*W*H)mm2500*1070*28402500*1070*2840
Prod Model: Z3040*16/1
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Spindle Taper: 4
Spindle Travel: 315mm
Main Motor: 3kw
N.W: 3500kg
Structure: Radial Drilling Machine
Layout: Vertical
Controlling Mode: Artificial
Automatic Grade: Semiautomatic
Precision: High Precision
Brief introduction

Zaozhuang Make Machinery Co., Ltd., located at Zaozhuang city Shandong province, which is the midway between Beijing and Shanghai, closed to Qingdao port, has been focusing on manufacturing machine tools for more than 20 years. This is an integrated manufacturing company which includes design, machining, assembly, installation, commissioning and after-sales service. With a long time experience in exporting machines, we are specialized in servicing international customers, and in particular, familiar with the quality standards from different countries. This enables us to supply our customers consistent high-quality products, as well as providing excellent customer services. Zaozhuang Make Machinery Co., Ltd. Is your ideal cooperative partner, with our continuing growth through dedicating ourselves to growth of our customers.

Strength

1. Dealing directly with the manufacture-----no middle man

2. The most competitive pricing in the market.

3. High-quality control standards, such as ISO, CE

4. Prompt attention to customer inquiries.

5. Diverse services for your needs, including sourcing other machinery and purchasing them as your agent, inspection goods for you by our engineers, the spare parts distribution, quality modifying, product process tracking and good delivery. The feedback to you will be within 24 hours.

6. Research and development to meet needs of customers and the market.

Product range

1. Plano miller: Series CNC Plano Miller, Series Plano Milling Machine, Series Gantry Milling Machine, Series Planer Milling machine

2. Series Guideway Grinding machine

3. CNC machine center

4. Series Conventional Milling Machine & Milling/ Drilling Machine

5. Drilling machine: Series CNC Drilling Machine, Series Radial Drilling Machine, Series Vertical Drilling Machine

6. Lathe: Series CNC Lathe, CNC Lathe-Inclined bed type

7. Hydraulic Press: Series Gantry Hydraulic Press, Series C-Type Hydraulic press, Series Hydraulic Bend

8. Garage equipment: Series Cylinder Boring Machine, Cylinder Honing machines, Series Brake Drum Boring Machine, Brake Lathe,

Brake Drum (Disc) Cutting Machine

9. Riveting Machine: Series Hydraulic Riveting Machine & Pneumatic Riveting Machine

10. Light Slotting Machine & Slotting Head

11. Bench Grinder & Vertical Grinding Machine

12. Series Arbor press

13. Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal boring head, Clamp kits, etc.

Research and Development

Our products are based on research and development to ensure needs of customers and the changing market.

Quality Control

Quality control is the key principle for Zaozhuang Make Machinery Co., Ltd. Our manufacturing has adopted modernized ISO Quality Management Systems, sound operational procedures as well as effective product and customer service system.

These systems ensure all products produced under very strict quality control, maintaining our high standards to ensure your ongoing success by using our products.

Quality guarantee period

We guarantee all our products to be defect free for one year from the date of purchase. Our after-sales service will cover any issue that may occur promptly.

Customer service

We have professional technicians to provide ongoing support for customers, during and after the guarantee period. We will attend your requests including large-type CNC machine tools installation and adjustment.

Special order

With our extensive experience in this industry, we are in the best position to meet needs of our customers, for both normal standard commodities and special orders. We guarantee to have the best price for your product based upon your detail requirements.

YOUR GOAL, OUR GOAL.
