Planetary Reducers for Container Cranes, Ship Unloaders, Coal Mining Machines
| Price: |
US $ 30-2000/Set |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Technical Specifications| Max. output torque Tmax N.m | Rotation Ratio | Hydraulic Motor | Max. input | Static brake torque Tbrmax. N.m | Brake working |
| rotating | pressure Mpa |
| r/min | |
| 13000 | 16.3,22.6,32.1,37.6 | A2FE45, A2FE56, A2FE63 | A6VE28, A6VE55 | 2000 | 450-900 | 1.8-5 |
| 17000 | 26.4,32.1,45.5,54 | A2FE45, A2FE56, A2FE63 | A6VE55 | 2000 | 500-1000 | 1.8-5 |
| 17000 | 77.9,88.2,102.6 | A2FE28, A2FE32, A2FE45, A2FE56 | A6VE28, A6VE55 | 2000 | 220-450 | 1.8-5 |
| 24000 | 90.1,102.6,120.5 | A2FE45, A2FE56, A2FE63 | A6VE55 | 2000 | 400-750 | 1.8-5 |
| 36000 | 67,79.4,100,116.6 | A2FE45, A2FE56, A2FE63, A2FE80, A2FE90 | A6VE55, A6VE80 | 2000 | 450-800 | 1.8-5 |
| 50000 | 84.2,91.1,99.8,125.7,146.4 | A2FE80, A2FE90 | A6VE80, A6VE107 | 2000 | 600-1100 | 1.8-5 |
| 60000 | 86.5,94.8,105.5,119.8,139.9,169.9 | A2FE80, A2FE90, A2FE107, A2FE125 | A6VE80, A6VE107, A6VE160 | 2000 | 800-1200 | 1.8-5 |
| 1100000 | 95.8,114.8,128.6,147.2,173.9,215 | A2FE107, A2FE125, A2FE160, A2FE180 | A6VE107, A6VE160 | 2000 | 900-2000 | 1.8-5 |
| 2200000 | 188.9,246.1,293 | A2FE107, A2FE125, A2FE160, A2FE180 | A6VE107, A6VE160 | 2000 | 1200-2400 | 1.8-5 |
| 3300000 | 168.9,209.9,252,302.4 | A2FE250, A2FE355 | A6VE250, A6VE355 | 2000 | 1500-3500 | 1.8-5 |
| Prod Model: |
speed reducer |
| Gearing Arrangement: |
Planetary Speed Reducer |
| Max. Output Torque: |
3136 |
| Single Wire Rope Force: |
14500 |
| Brake Torque: |
190 |
| Hydraulic Motor: |
A2f56W6.1z2 |
| Input Rotation Speed: |
2000-3000 |
| Weight: |
160 |
| Color: |
Any Color |
| Applications: |
Crane,Conveyor |
| Material: |
Steel |
