| Price: | US $ 613-798/Square Meter |
|---|---|
| Min Order: | 1/Square Meter |
| Pay Type: | T/T,D/P,Western Union,Paypal |
1.High refresh no scan lines when taking video and pictures .
2.High gray level, it can reach 16bit , and refresh rate is more than 2000HZ.
3.IP65 standard,dustproof and waterproof .No problem to work for long time outside.
all weather available.
4. High brightness, over 6000 nits, can work well in day time even under direct sunshine.
5.Good LEDs: it has excellent performance in antistatic ability and UV protection.
6. Dual back-up:both power supply and system dual back-up are optional,reliable
performance.
| Pixel Pitch | 4mm | 5mm | 6mm | 8mm | 10mm |
| LED Lamp | SMD2727 | SMD2727 | SMD3535 | SMD3535 | SMD3535 |
| Density | 62500dots/sqm | 40,000dots/sqm | 27,777dots/sqm | 15,625dots/sqm | 10,000dots/sqm |
| Module Size | 256*128mm | 320*160mm | 192*192mm | 320*160mm | 320*160mm |
| Weight | 0.35Kg | 0.5kg | 0.369kg | 0.474kg | 0.51kg |
| Scan Mode | 1/8 | 1/8 | 1/8 | 1/5 | 1/2 or 1/4 |
| Refresh Rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥3600Hz |
| Brightness | ≥7,000nits | ≥7,000nits | ≥6,500nits | ≥6,500nits | ≥7,500nits |
| Viewing Distance | 4m-100m | 5m-100m | 6m-40m | 8m-40m | 10m-50m |
| Max power consumptiom | 1000w/sqm | 980w/sqm | 950w/sqm | 780w/sqm | 880w/sqm |
| Avg power consumptiom | 450w/sqm | 390w/sqm | 380w/sqm | 320w/sqm | 350w/sqm |
| Best Viewing angle | 160°(H)/120°(v) | ||||
| Grey scale/colors | 65,536 level(color range 281 trillion) | ||||
| Processing depth | 16bit | ||||
| Brightness control | 256 levels automatically | ||||
| MTBF | >9,000hours | ||||
| Lifetime | 100,000hours | ||||
3.Product Details
4.Products Package
• Packing: Anti-shaking wooden
• Shipping:By sea, Air,Express
• Shipping port: Shenzhen. China
7.Trade Terms:
1.Payment: T/T , Western Union or Paypal are welcomed.
2.Production lead time for 100~500pcs: 10days, 500~1000pcs:15days
3.Sample can be delivered in 3days
4.Shipping freight are quoted under your requests
5.Shipping port: Shenzhen, Mainland China
6.Discounts are offered based on order quantities
7.MOQ:1pcs
Our Service:
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into
product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information.
| Prod Model: | P10 |
|---|---|
| Pixel: | 10mm |
| IP Level: | IP65 |
| Max Power Consumption(W/M2): | 1000 |
| Module Size(mm): | 320*160mm |
| Tube Chip Color: | Full Color |
| IP Rating: | IP65 |
| Pixel Pitch: | 10mm |
| Pixel Configuration: | 1R, 1G, 1B |
| Display Function: | Market Display |
| Average Power Consumption: | 300W / m² |
| Pixel Density: | 10000 dot / m² |
| Scanning Mode: | 1/2 Scan |
| Display Type: | LED Video Display |
| Application: | Advertising |
| Certification: | ETL |
