New Xcm Xz180 Horizontal Directional Drill

New Xcm Xz180 Horizontal Directional Drill
Price: US $ 100000/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T

XCM XZ180 Horizontal Drictional Drill


 (97KW) engine, 180kN of push-pull, 6000N.m of Max.spindle torque, motor dual speed chain push-pull system, self-propelled rubber tracks chassis, automatic loading and unloading drill rod device, rotatable control board, patent technology for floating vice, and onboard high-capacity mud pump (250L/min).


Specification:

XCM XZ180 Horizontal Drictional Drill

XCM XZ180 Horizontal Drictional Drill

XCM XZ180 Horizontal Drictional Drill

XCM XZ180 Horizontal Drictional Drill

XCM XZ180 Horizontal Drictional Drill



Model

XZ180

Engine



Rated power

kW

97

Max.pullback/thrusting

kN

180/180

Spindle torque(max)

N.m

6000

Spindle speed

r/min

0-140

Backreaming diameter

mm

Ø600

Tubing length(single)

m

3

Tubing diameter

mm

Ø60

Entry angle

°

10-22

Mud flow rate(max)

L/min

250

Mud pressure (max)

bar

80

Overall weight

kg

10000

DIMENSION (LxWxH)

mm

6400×2270×2340
(97KW) engine, 180kN of push-pull, 6000N.m of Max.spindle torque, motor dual speed chain push-pull system, self-propelled rubber tracks chassis, automatic loading and unloading drill rod device, rotatable control board, patent technology for floating vice, and onboard high-capacity mud pump (250L/min).







Prod Model: XCM XZ180
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Power: 98kw
(97kw) Engine: (97kw) Engine
180kn: 180kn
Usage: Construction
Type: Magnetic Drill
