Made-In-China: http://evangelchina.en.made-in-china.com www.facebook.com/evangelchinaXCM 1000KN Push/Pull Force Horizontal Hole Directional Drilling XZ1000
XZ1000 adopts many advanced control technologies such as PLC control, electro-hydraulic proportional control, load sensing control, and etc.
·The drilling shaft can be mounted and dismounted automatically, so as to improve the work efficiency and reduce the labour intensity and manual misoperation and thus reduce the work staff and reduce the production cost.
·Automatic anchoring: the hydraulic pressure drives the anchor, which features large anchoring force, simple and convenient operation.
·Dual speed power head: drilling and dragging at low speed to ensure that it works smoothly; sliding at quick speed to reduce the auxiliary time and make higher work efficiency during the disassembly of drilling rig with empty load.
·The engine has the feature of turbocharged torque increase, which can increase the power instantaneously when encountering tough terrains to ensure the drilling power.
·The power head features high speed, good boring effect and high efficiency.
·Multiple operation with single handle control, convenient for accurate control, simple and comfortable operation.
·With tethered control, it is safe and efficient for single operator to load and unload the drilling rig.
·The patented float clamp can effectively prolong the service life of the drilling shaft.
·With multiple safety protection functions and the alarming system on the engine and hydraulic parameter, the operator and the machine are safely protected.
Parameter
Model | | XZ1000 |
---|
Engine | | |
Rated power | kW | 392 |
Max.pullback/thrusting | kN | 1000/1000 |
Spindle torque (max) | N.m | 55000 |
Spindle speed | r/min | 0-80 |
Backreaming diameter | mm | Ø1200 |
Tubing length(single) | m | 9.6 |
Tubing diameter | mm | Ø127 |
Entry angle | ° | 10-18 |
Mud flow rate (max) | L/min | 1200 |
Mud pressure (max) | bar | 200 |
Overall weight | kg | 32000 |
Dimension(LxWxH) | mm | 14500×3150×3390 |
