in Stock 1000*2000mm Reparable Block Air Pushing Bag

in Stock 1000*2000mm Reparable Block Air Pushing Bag
Price: US $ 100-800/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 10/Piece
Pay Type: L/C,T/T,Western Union
Reparable&Reusable!Used to push over block after it was cut by the diamond wire saw machine.

The thickness is less than 7 mm.It can be put into the cutting gap easily.
After inflation by air compressor, the pushing power of the air bags can reach 50 tons to 450 tons according to different sizes of the pushing bags.

Polymer blocks pushing air bag is used to separate the marble, granite, stones(rock mass) block from the basic rock achieving a maximum opening of 45cm at the top.The air bag can separate the block (rock mass) which is having all side wire saw cut faces.

The standard configuration set:
Each set contains two air bags, with one set of air pipe & air control panel.

Materials:
A:Ordinary material--You could repair it with glue when it is carelessly lacerated.
B:Special material--It's not easily lacerated, so it's no necessary to repair it.

Online Video:HTTP://www.Youtube.COM/watch?V=CJzIB9BBMEc

Pushing air bag is often used in stone quarrying after cutting by wire saw.High-materials
And special processing technique.

Advantages:
1.Less than 7mm thickness
2.Strong pushing power
3.High-tech materials and special processing techniques
4.No frequent problem in split and damage
5.Can be reused
It's max pushing capacity could reach to 200 tons.

IT CAN BE USED FOR MANY TIMES;SOME OF OUR CUSTOMERS JUST USE ONE BAG
ONE YEAR!
ModelSpecificationTheoretical pushing capacityWeight(kg)
BL10101.0m×1.0m50tons4.5
BL10151.0m×1.5m75tons6.8
BL10201.0m×2.0m100tons9.0
BL15151.5m×1.5m115tons10.2
BL20152.0m×1.5m150tons13.5
BL20202.0m×2.0m200tons18.0
BL30303.0m×3.0m450tons40.5
Control platfrom for above air bagair pressue 0-6bar,3 outlet30.0


Catalogue download:

1.General catalogue: http://www.quarryingtools.com/downloadRepository/fc6d7f13-fd64-474e-96b7-ccc7a78b84aa.pdf
2. Expansive mortar: http://www.quarryingtools.com/downloadRepository/d7a67d54-4fc2-426b-ac71-3526df69b790.pdf
3. Rock drill tools: http://www.quarryingtools.com/downloadRepository/8c890428-2bf1-4b33-b5c9-1373a2c23962.pdf
4. DTH rock drill tools: http://www.quarryingtools.com/downloadRepository/9d3c352e-dd2d-4e11-8ad8-13dc8045bda7.pdf

Contact Us:

Ms Roxane Xue
Add: Unit 8001, No.350, Changle Road, Huli District, Xiamen, China.361006
Tel : +86 592 5681392/5601702
Fax : +86 592 5601703
Web Site : http://www.quarryingtools.com
                  http://www.split-stone.com
Prod Model: BL1010,BL1015,BL1020,BL1515,BL2015,BL2020,BL3030
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Thickness: Less Than 7 Mm
Pushing Capacity: 50 Tons- 450 Tons
Application: for Big Blocks and Walls Pushing
Low Cost: Repairable and Reusable
Control Platfrom: Air Pressue 0-6bar, 3 Outlet
Stone Type: Marble, Sandstone, Slate, etc
Color: Yellow/Red/Blue
Usage: After Cutting by Diamond Wire Saw Machine
Size: According to Your Special Requests
Delivery Time: Within 15days After Receipt Your Full Payment
Xiamen Bestlink Factory Co., Ltd.Is committed to providing the best drilling and cutting machines, tools and accessories products in marble and granite stone quarrying, as well as in civil engineering application, especial demolition project.Our company is now a leading manufacturer of cutting and drilling equipment for the extraction of marble, granite and ornamental stones in China.

Since 1985, we have produced and supplied high quality Split AG Non-Explosive Demolition Agent to our worldwide customers in the quarrying and demolition industries.

From early 2000, we have made a start in the study and developed the Hydraulic Rocks and Concrete Splitters by patent inventions, and reached a great success in the domestic and overseas market.Now, we are only a producer and exporter just now from China.

In 2004, we developed and produced the patented products:Hydraulic Rock Drill, Stone holes Groover, Stone Crack Expander and Hydraulic Rock Breaker.We offer a vast range of hydraulic and pneumatic drills and machines for diamond wire cutting as well as all kinds of accessories for quarrying activities.

Now, quality products are being exported to more than 45 countries and regions all over the world including the USA and Europe with high reputation.

We are continually looking for ways to develop drilling and cutting technology for quarrying and demolition, and hoping to be the world No.1 company about quality and prices of hydraulic Splitters and Expansive Cement within 5 years.Thank you very much for your support and wish to get your deep interest and be your best partner.
