Horizontal Directional Drill XZ280
The horizontal directional drill is mainly used for laying and replacing various underground pipelines. The machine features advanced performance and high operation efficiency and comfortable working condition. The key components are purchased globally, and it is the ideal equipment for construction in industries of water supply, coal gas, electric power, telecommunication, heating and oil.
Speciality parameter | Model | | CPCD20() | CPCD25() |
Power type | | Diesel | Diesel |
Rated capacity | kg | 2000 | 2500 |
Load center | mm | 500 | 500 |
Lift height | mm | 3300 | 3300 |
(/)Mast tilt angle (forward/backward) | Deg | 5/15 | 5/15 |
Front overhang | mm | 550 | 550 |
Wheel-base | mm | 1850 | 1850 |
(/)Tread(front/rear) | mm | 1250/1205 | 1250/1205 |
Performance parameter | Travel brake | | -Hydraulic-Foot pedal |
Parking brake | | -Mechanical-Hand level |
(/)Lift speed(with/without load) | mm/s | 400/520 | 400/520 |
(/)Lower speed (with/without load) | mm/s | (with load)<600 ,(without load)>300 |
(/)Travel speed (with/without load) | km/h | 18/23 | 18/23 |
()Max. gradeability (with load) | % | 20 | 17 |
Power, transmission and others | Engine | Model | | A495BPG | A495BPG |
Manufacturer | | Xinchang | Xinchang |
Rated power | kw | 42/2650 | 42/2650 |
Max.roration | | 174/1800 | 174/1800 |
Dispilacement | | 2.98 | 2.98 |
Battery | Voltage | V | 12 | 12 |
Capacity | Ah | 100 | 100 |
Gearbox | Transmission type | | Hydraulic |
(/)Gears,speed (front/rear) | | I/I | I/I |
Tire | type | | Spare tyres |
Model | Pront | | 11.5/80_15.3_14PR |
Rear | | 27×10_12_12PR |
Other | Self.weight | kg | 4500 | 4750 |
Free lift height | mm | 120 | 120 |
Fork | ××Thickness×Width×Length | mm | 40×125×1070 | 40×125×1070 |
Overall dimensions | ()Overall length(without forks) | mm | 2845 | 2910 |
Overall width | mm | 1480 | 1480 |
Overall height | Extended height(mast) | mm | 4270 | 4270 |
Lower height(mast) | mm | 2310 | 2310 |
Overhead guard | mm | 2515 | 2515 |
Min. turning radius | mm | 2900 | 2940 |
Min. under ground clearance | Under mast | mm | 220 | 220 |
Center of wheel-base | mm | 310 | 310 |
