High Quality Car Battery Electric Power Converter

Name: High Quality Car Battery Electric Power Converter
Brand: tool-buy.com
SKU: 711566462
Availability: InStock
Rating: 4.6 (26 reviews)

Price:	US $ 30/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Future Green Technology Co., Limited

Showroom Product Company Profile

High Quality Car Battery Electric Power Converter

Features:
1.Pure sine wave output
2.CPU control technology; SCM control
3.Strong ability of impact resistance
4.Wide input voltage range: 90-280V; Four step AVR (three step boost, one step reduction voltage)
5.Protection against overload, short-circuit, overvoltage, under-voltage and over-temperature, etc.
6.Anti reverse connection protection and high-low voltage protection(option)
7.Special overload protection: When it is overload, it will lock the unit automatically, when it restores, it will restart the unit automatically again.
8.Strong inverter ability. It can change frequency immediately and it is able to drive the inductive load such as air conditioner, refrigerator, motor, etc.
9.Powerful charge current
10.LED or LCD display (option)
11.Meet the need of different power supply
12.Use MOSFET and IGBT

Product Details:

Protect function:
1. Lack-voltage alarm protection
2. Low-voltage protection
3. Over voltage protection
4. Over load protection
5. Short-circuit protection
6. over temperature protection
7. AC input low voltage protection
8. AC input over voltage protection
9. Battery reverse connection protection (Optional)
Application:
1.Power Supply Field: Solar System, wind power system, gas discharge lamp and etc.
2. Household Appliances: lamps ,refrigerator,TV,washing machine,electric fans, vacuum cleaner, air conditioner, satelliate receiver, micro-wave oven, induction cooker etc.
3. Office area: Computer, printer, copier, scanner, digital camera and etc.
4. Power tools series: Electric saw, drilling machine, punching machines, air compressor etc.
5. Irrigating system:solar pumping system
6.Traffic Devices: Military vehicle, police cars, medical ambulance, ships, traffic lights, and etc.

Pure Sine Wave Solar Power Inverte With Controller Technical Specifications
Model		1000W		2000W	3000W
Inverter Rated capacity(W)		1000W		2000W	3000W
Inverter Input	Rated Battery Voltage	12V	24V	24V	24V	24V	48V
	Commercial Power range (VAC)	100/110/120/127/220/230/240 (+25%,-35%)
	Frequency(Hz)	50±0.5/60±0.5
Solar Input	Input power(W)	240W	720W	720W	960W	1200W	2400W
	Maximum power (WP)	480WP	1440WP	1440WP	1920WP	2400WP	4800WP
Solar Controller (Optional)	Control Type	PWM or MPPT (Optional)
	Rated Voltage	12V	24V	24V	24V	24V	48V
	Rated Current	20A	30A	30A	40A	50A	50A
	Equilibrium charging	29V					58V
	Float charging pressure	27.4V					54.8V
	Under voltage protection	22.2V					44.4V
Inverter Input	Commercial Power range (VAC)	100/110/120/127/220/230/240 (+25%,-35%)
	Frequency(Hz)	50±0.5/60±0.5
Inverter Output	Rated capacity	1000W		2000W	3000W
	Waveform	Pure sine wave
	Frequency(Hz)	50±0.5/60±0.5
	AVR voltage range(VAC)	100/110/120/127/220/230/240±10% (Auto-sensing )
Protection	Over Load Protection	30 seconds delay shutdown for 105~130% exceeded
Battery	Type	Sealed, maintenance-free lead acid
	Battery protection	Automatic self-test, discharge protection, over-charge protection, smart management system.
	Recharge current	30A(Maximum)
	DC voltaget	24VDC					48V
	battery input voltage range	DC:22V~30V					DC:44V ~60V
Working Environment	Working Temperature	0ºC ~ 40ºC (0m~1500m)
	Noise	60dB
	Store Temperature	0ºC ~ 40ºC
	Humidity	<95%
Size(LWH)		470210350mm			470260500mm
Packing Size(LWH)		540270400mm			540320560mm
Net weight(kg)		15	15	21	33	33	34
Gross weight(kg)		19	19	25	37	37	38
Pure Sine Wave Solar Power Inverte With Controller Technical Specifications
Model		5000W		8000W		10000W
Inverter Rated capacity(W)		5000W		8000W		10000W
Inverter Input	Rated Battery Voltage	48V		96V	192V	96V	192V
	Commercial Power range (VAC)	100/110/120/127/220/230/240 (+25%,-35%)
	Frequency(Hz)	50±0.5/60±0.5
Solar Input	Input power(W)	2400W		4800W	19200W	4800W	19200W
	Maximum power (WP)	4800WP		9600WP	38400WP	9600WP	38400WP
Solar Controller (Optional)	Control Type	PWM or MPPT (Optional)
	Rated Voltage	48V		96V	192V	96V	192V
	Rated Current	50A		50A	100A	50A	100A
	Equilibrium charging	58V		116V	232V	116V	232V
	Float charging pressure	54.8V		110V	220V	110V	220V
	Under voltage protection	44.4V		88.8V	178V	88.8V	178V
Inverter Input	Commercial Power range (VAC)	100/110/120/127/220/230/240 (+25%,-35%)
	Frequency(Hz)	50±0.5/60±0.5
Inverter Output	Rated capacity	5000W		8000W		10000W
	Waveform	Pure sine wave
	Frequency(Hz)	50±0.5/60±0.5
	AVR voltage range(VAC)	No
Protection	Over Load Protection	30 seconds delay shutdown for 105~130% exceeded
Battery	Type	Sealed, maintenance-free lead acid
	Battery protection	Automatic self-test, discharge protection, over-charge protection, smart management system.
	Recharge current	30A(Maximum)
	DC voltaget	48V		96V	192V	96V	192V
	battery input voltage range	DC:44V~60V		DC:88V~120V	DC:176V~240V	DC:88V~120V	DC:176V ~240V
Working Environment	Working Temperature	0ºC ~ 40ºC (0m~1500m)
	Noise	60dB
	Store Temperature	0ºC ~ 40ºC
	Humidity	<95%
Size(LWH)		470260500mm		550260710mm
Packing Size(LWH)		540320560mm		620330770mm
Net weight(kg)		42		72	72	82	82
Gross weight(kg)		46		77	77	87	87
Remarks	Specifications subject to change without prior notice
	Our company accept customized special specifications products

Warranty: two years
If you can cooperate with us, we will be honored and you will benefit from:
1. Professional engineers and professional analysis equipements and testing decives support professional aftersales services
2. The good construction warranty is 2 years
3. Your client will be satisfied on the right schedule and quality
4. Your can get good reputation from your market and obtain more orders
5. The free inverter samples will be provided after your first 2 orders
6. The reasonable prices
7. Any question from you are welcome and will be replied in 24 hours.

Prod Model:	FG1006
Item Name:	Wholesale DC to AC Pure Sine Wave Power Inverter
Size:	428360225mm
Color:	Black
Output Voltage:	220V
Output Frequency:	50/60Hz
Continuous Output Power:	300W
Max. Output Power:	600W
Max. Efficiency:	90%
Output Wave Form:	Pure Sine Wave

Hello, friends. We are a company with two factory called Future Green Energy Technology based in Guangzhou China. FGET provides solar power system and kinds of batteries globally.

Future Green Energy Technology, is your personal home clean energy solutions provider. This company is a future-oriented Emerging company, is committed to provide clean energy for global world.

The first main product is automotive battery and sealed lead acid battery, which is mainly used for car, truck, taxi, bus, ship, solar, UPS, etc^

The Company has ventured into retail market segment and has nationwide presence through a network of branch offices and channel partners. The Company focuses on being a responsible corporate citizen through active participation in solar power projects and also working with electric vehicles manufacturers.

Commitment to quality, consistency, innovation and service is taking the Company through a steady growth in the competitive market. The Company is ISO certified.

Website: www.fget4u.com
