High Efficiency Grinding Hard Usage Resin Bond Diamond Grinding Wheel For Glass

High Efficiency Grinding Hard Usage Resin Bond Diamond Grinding Wheel For Glass
Price: US $ 10-60/Piece
Min Order: 10/Piece
Pay Type: L/C,T/T,D/P
Metal Diamond Cup Grinding Wheel for Glass Edging

Description: metal bond diamond grinding wheel, for short as diamond wheel. Produced by fusion of copper powder and diamond by high temperature and high pressure. Emery raw material is imported with high quality. Mainly used for glass processing bilateral edge grinding of 1 # rough grinding wheels.It's call full tooth diamond wheel because working surfaces appear jagged . Dentate working layer provide space for drainage and chip removal when working, reduce the temperature of the working face. Stress makes the glass won't be burned or chipping because of the temperature pressure too high. so as to improve the cutting strength and wear resistance. The product has characteristic of wear-resisting and good sharp nest.  bilateral edge grinding of 1 # rough grinding wheels commonly used diameter 175mm 100 # wheel. It can also be chose the appropriate grinding wheel based on customer's actual processing requirements.

Application:diamomd grinding wheels for straight line and bevelling machines,
double line machines,CNC machines

Suit for:glass,safety glass,tempered glass,architectural glass,frosted glass,patterned glass,Insulated glass,laminated glass,glass brick,optical glass,Auto Glass,solar glass




Typical Products:
Diamond Grinding Wheel for Glass
ItemDiameter (mm)Width (mm)High (mm)
Hole
(mm)
Grit
(#)
Diamond Grinding Wheel - Full Segment175151012/22/50/Other80#/100#/180#/200#/240#/300#/400#
150151012/22/50/Other80#/100#/180#/200#/240#/300#/400#
130101012/22/50/Other80#/100#/180#/200#/240#/300#/400#
Diamond Grinding Wheel - Internal Segment 17581012/22/50/Other80#/100#/180#/200#/240#/300#/400#
175151012/22/50/Other80#/100#/180#/200#/240#/300#/400#
150101012/22/50/Other80#/100#/180#/200#/240#/300#/400#
Diamond Grinding Wheel - Continuous1508812/22/50/Other80#/100#/180#/200#/240#/300#/400#
15061012/22/50/Other80#/100#/180#/200#/240#/300#/400#
130101012/22/50/Other80#/100#/180#/200#/240#/300#/400#
1308812/22/50/Other80#/100#/180#/200#/240#/300#/400#
Diamond Grinding Wheel - Outer Segment15081012/22/50/Other80#/100#/180#/200#/240#/300#/400#
Diamond Grinding Wheel - Resin150151212/22/50/Other80#/100#/180#/200#/240#/300#/400#
150151012/22/50/Other200#/240#/300#/400#/500#/600#
130101012/22/50/Other200#/240#/300#/400#/500#/600#
 REMARK:OTHER SPESC SPECS ARE AVAILABLE UPON REQUEST.










Procedure







Prod Model: HKL1030
Abrasive: Diamond
Types: Surface Grinding Wheel
Shapworking Stylees: Edge Shape
Working Style: Surface Grinding
Body Material: Iron/Aluminum/Stainless Steel
Grit: 80--600#
Usage: Grinding, Polishing
Tooth Profile: Continuons/Segment
HENKOOLEE TRADING LIMITED mainly engaged in exporting machinery & consumable products of ceramic tile produce process. We have an expert team, who can be consultant for new ceramic plant design, machinery technology modification of existed production line, all of them have more than 10 years experience in this ceramic field.

Since 2008 till today, we are doing business mostly with Indian ceramic factories, during this period, we keep choosing best suppliers of China for our Indian friends, however, every ceramic factory has the difference, we take the responsibility to look for the proper supplier for clients need. Fortunately, our clients satisfy the machinery manufacturers we suggested in these years, so mostly these manufacturers became fixed suppliers, and due to this reason, clients became our good friends gradually, the cooperation between our three parties goes very well.

Our company aim: Quality is the first, based on solving problems for clients as our friends, try our best to do top service and low down the produce cost. In the future, we will stick to our aim, adhere the principle of doing all work sincerely & seriously. Let's forge ahead, business scale is continually expanding!
