HDPE Double-Wall Corrugated Pipe for Water Drainage

HDPE Double-Wall Corrugated Pipe for Water Drainage
Price: US $ 11-20/Piece
Min Order: 100/Piece
Pay Type: L/C,T/T,Western Union,Money Gram


Introduction

High Density Polyethylene (HDPE) Double Wall Corrugated Sewer and Drainage Pipes are for gravity and low pressure sewerage and drainage such as waste water, sanitary sewer and storm sewerage for municipal or industrial use. The pipes provide important benefits and distinct advantages for sewer and drainage applications.


Application Area

Because the steel reinforced spiral HDPE drainage pipe is the perfect combination with all merits of ordinary non-press plastic pipes and high strength of steel reinforced segments, it can meet all demands in project applications completely. It can be widely used in gravity delivery with various media of corrosive or non-corrosive environments. Such as:

1.      Road engineering: used for railway, highway seepage, drainage tube.

2.      Municipal engineering: used as underground drainage, sewage pipe.

3.      The landfill and sewage collection pipe.

4.      Building engineering: used for building the rain water pipe, underground drainage pipe, drain pipe, vent pipe etc.

5.      The industry: widely used for the waste pipe industry.

6.      The large port, wharf engineering: large airport, port, wharf engineering drainage, sewage pipe etc.

Features and Benefits

1.      Distinguished comprehensive performance

Worked as the braced structure, the steel belt offers enough ring stiffness to resist soil loading. HDPE pipe has excellent characteristic, high ability of internal and external corrosion prevention and moderate axial toughness. And steel reinforced spiral HDPE drainage pipe is integrated advantages of steel and plastic. Therefore the pipe owns distinguished comprehensive performance.

2.      Safe and reliable ring stiffness

Steel and plastic have excellent modular ratio and weight ratio, and their ratios are over 200 and 7.85 respectively. Strengthening the steel belt could be easily provided the pipes with enough safe and reliable ring stiffness and extremely high weight ratio when compared with pure plastic pipes.

3.      Light weight

Steel reinforced spiral HDPE drainage pipe has very high stiffness weight ratio, therefore, its weight is lighter than any other pure plastic pipes with the same ring stiffness.

4.      Simple installation, good sealing and low cost of construction

Large-scale handing appliance is not required when installing the light weight pipes. Because of its good axial toughness, requirement of the undercut flatness are low when laying and fixing. Moreover, it has good capacity to bear abnormal stress caused by improper assembly. All sealed placements can be manually operated with simple equipments, simply and quickly without any leakage.

5.      Strong load capacity

Because the pipes are with high ring stiffness and good axial toughness, when burst load and disasters like soil differential settlement, ground water level rising, overload of part of the ground and earthquake happen, the stress can be defused the elastic deformation of the pipes to avoid the leakage and damage of the pipe connections.

6.      Other advantages

Anticorrosion, anti-ultraviolet, smooth inner wall, impact resistance, nonpoisonous, abrasion resistance and long lifespan.



Company Advantage

1. Professional :

We have rich experience in produce pipe and pipe fitting for many years, we are first class manufacture in China

2. Best Price :

Give our customer most favorable price while providing the highest quality product.

3. Best Service :

Engaged in exporting for many years, we will give the perfect solution for any feedback from our customer.

Physical Properties of the Pipes

Item

Requirement

Ring Stiffness (KN/m2)

SN4

≥4

SN8

≥8

SN10

≥10

SN12.5

≥12.5

Impact Property (TIR)

≤10%

Flexible Ring

The sample is smooth, no reversed bending, no breakage, the reinforcing ribs will not fall off the pipe body.

Oven Test

No breakage and leakage

Creep Ratio

≤2

Tensile Strength (N)

200≤DN/ID≤300

380

400≤DN/ID≤500

600

600≤DN/ID≤800

840

900≤DN/ID≤1900

1200

2000≤DN/ID≤2600

1440

FOR MORE INFO, WELCOME TELL US!






Contect us:
A-TECH PIPE INDUSTRY Co.,Ltd.
Name : Angela Jiang
Department: Sales Department
Title: Sale Manager
Phone: +86-186 2153 5086
Add: Zhuma Industry Area, Lianshui Town, Huaian City, Jiangsu Province.


Prod Model: AT-2701
Usage: Water Drainage
Materials: HDPE Pipe
Compound Material: Plastic Composite Pipe
Material: PPR-Al-PPR
Installation And Connection: Clamping Type Installation
Technology Of Plastic Composite Pipe: Rotational Molding
Base Pipe Of Plastic Composite Pipe: Welded Steel Pipe
Internal Coating Materials Of Plastic Composite Pipe: Polyethylene Coating Steel Pipe
Plastic Composite Pipe Coating Form: Inner Coating
Plastic Composite Pipe Model: GS-—X-SP-T-EP
Steel Skeleton PE Pipe Use: Oil Pipeline
Aluminium Plastic Compound Pipe Use: Water Distribution Pipe in Building
Steel Plastic Composite Pipe Model: GS-—X-SP-T-EP
Aluminium Plastic Compound Pipe Material: High Density Polyethylene Aluminum Composite Pipe
A-Tech PIPE Industry was founded in 2016, mainly produces PVC-U water supply and drainage pipe, MPP cable protection pipe, HDPE double wall corrugated pipe, CPVC Electric Power Protection pipe and other products, widely used in Building water supply and drainage, electric power cable protection and other areas. The company has passed the ISO9001 quality management system certification, ISO14001 environmental management system certification, OHSAS18001 occupational health and safety management system certification. OHSAS18001 occupational health and safety management system certification, pressure pipeline components manufacturing license certification, CCC mandatory product certification and other access system. A-Tech will accelerate the pace of innovation, and constantly strengthen the standardized management at the same time, actively explore the market, the development of environmentally friendly building materials in the field of development opportunities, the company building become China's largest, most powerful and most attractive modern enterprise.
