Fixed Drilling Machine Bore Well Stone Drilling Machine Price

Fixed Drilling Machine Bore Well Stone Drilling Machine Price
Price: US $ 1-3999SET
Min Order: 1SET
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Fixed drilling machine bore well stone drilling machine price

What is the features of our drilling rigs?

1. The captioned water well drilling machine is a kind of light and high efficient multifunctional water well drill rig with steel track. This kind of drilling machine is widely used in engineering construction for drilling wells, monitoring wells and groundsource heat pump airconditioner, and also applied in hole blasting, bolting and anchor cable, etc.
2. Bracket installed on the hosit which forms a double wheel support structure and it is capable to withstand strong blow.
3. Vertical box are fixed by four groups of bearings to ensure that the rotary machine has sufficient rigidity to overcome gravel layer and other complex geological conditions.
4. The machine is equipped with national patent technology---taper clutch, with charactristics of strong transmission troque, easy operation and free maintenance.
5. 53 x 59 drilling rod adopted, high rigidity and strong delivery torque.

Our machine is applied to general investigation, geophysical survey, road and tall building base prospecting, drilling projects like water well, blast hole and so on. According to different geological conditions, you can choose drilling bit kinds: diamond, alloy and steel particles to drill.

Drilling Machine Technical Parameter
ModelHH130YHH180YHH200Y
Drilling Depth(m)130180200
Open hole dia.(mm)220220325
End hole dia.(mm)757575
Drill rod dia.42-6042-6042-60
Drilling angle(°)90-7590-7590-75
Matching power(kw)13.213.214.7
Weight without power600/740620/750880/970
Dimension(m)2.4*0.8*1.42.4*0.8*1.32.7*0.9*1.5
Spindle Speed(r/min)142/285/570130/300/480/730
/830/1045
64/128/287/557
Spindle Stroke(mm)450450450
Winch max. pull force(kg)200021002500
Winch pull speed(m/s)0.41-1.640.35-2.230.12-0.95
Winch rope dia.(mm)Φ9.3Φ9.3Φ12.5
Winch roll capacity(m)272735
Drill mast rated loat(ton)181818
Drill mast Height(m)6.56.56.5
Mud pump flow(l/min)9595145
Mud pump max. pressure(Mpa)1.21.22
Mud pume times/min939393
Intel hos dia.(mm)515151
Outlet hose dia.(mm)323238

Packaging & Shipping
We package our product with standard export wooden carton or as customized packaging guideline. We have close cooperation with a number of experienced shipping agents and we deliver our machines in FCL or LCL, both are available for our customers.

Why Choose Us HENGHUA ?
Customer's satisfaction is our success. HENGHUA will assist customers to build product lines at any time any place. We can supply our customers products, at the same time with technical support and professional service. HENGHUA endeavor ourselves to render best relationship, friendship and high reputation from overseas customers.

What Certificate & Quality Assurance We Have?
We have obtained a number of qualified certificates from international quality assurance organization, such as ISO9001:2000, CE certified, SGS 3-party verifications, etc. We welcome customers with high and strict quality requirement so that we could get win-win cooperation and improve mutually hand in hand

Why We Are Popular in Global Market ?
1. Quality Guarantee and High Reputation in Global Market
    100% environmental protection material, easy to deal with all environmental requirements
    100% quality warranty and maintenance
2. Rich Experience and Focus on Machines Manufacturing for Many Years
    We are professional drilling rig machine manufacturer and have been engaged in this field for many years.
3. Strict Process Control and Advanced Management
     We have our own process control system and under the joint effort of workers and engineers, we build and supply perfect machines.
4. High Quality, Best Service and Competitive Price
    "Honesty is the best policy and quality is the best honesty" is our motto. So we always provide our products with high quality and best service.
5. Various drilling rigs with different types and models
    We can provide you machines in different models and functions as your specified demand.
6. Perfect Equipment and Superior Technology
    We have our own factory and first-class equipment and our own engineers.
7. Meet International Standard and Passed the ISO9001:2000 and CE Certificate
    We have the related certificates and provide our customer for reference.
8. Prompt Response & Delivery
    Nearby Tianjin port and we can delivery faster. Once you have any question, we will give you reply on time.

FAQ
Q1: Are you a manufacturer?
A: Yes, we are a professional drilling rig and its parts manufacturer.
Q2: What does your company produce?
A: The main products of our company include rotary drilling rig, Kelly bar, drilling bucket, drilling auger, casing oscillator, desander and tricone bit, etc.
Q3: How about your delivery time?
A: Normally the delivery time is about 35 days. For some special case, we can make it within 2 weeks, it depends on different products.
Q4: What methods of payment do you accept?
A: We accept T/T, L/C, Western Union or as customer requested
Q5: What is the MOQ?
A: Small trial order is acceptable, like 1 set, 2 sets…
Q6: Do you offer any deals or discounts?
A: Yes, price depends on different quantity, different quantity will give you different price.

Contact Us Now!

Jenny Wang
Mob+8618902080672
Tel: 86-22-83859655
Fax: 86-22-83862303

Company website: www.hhgpipe.com



Prod Model: HH180
Power Type: Diesel
Usage: Coal, Ore, Water Well, Geotechnical Investigation
Voltage: 380V
Power (W): 13.2
Dimension: 2400*800*140
Weight Without Power: 620kgs
Warranty: 12 Months
After-Sales Service: Overseas 3-Party Support
Dilling Depth: 180m
Drill Rod Dia.: 42-60mm
Tianjin Henghua Pipeline Technology Co., Ltd is the member of HeBei Bohai GROUP a professional manufacturer. As far, we have three branches for 3 main machines. We adhere to "quality oriented, credibility first" business philosophy, striving to provide users around the world perfect machines at the advantages of our strong brand, technology and services.

We have skillful production people and strong R&D technicians who have accumulated over 26 years experience in machinery, "Best quality, best service and most competitive price" is our principle.

Drilling rigs

Our brand is recognized worldwide for our high quality, reliability and our customer service. Our drilling rigs are widely applicable for water well, farm irrigation, geological prospecting, small pile foundation, geothermal air-conditioner and so on, capable and functional. Henghua has a professional team of engineers with rich experience in the design, production and inspection.

Hydraulic Machines

We produce high quality Hose crimping machine, hose cutting machine, hose assembly, hose skiving machine, flexible axle crimping machine, and nut crimping machine and so on. They are widely used in navigation, military industry, engineering machinery, and mine exploitation, steel, shipping manufacture, oil field, drilling rigs, flexible axle produce, agricultural equipment etc. Our products are well accepted all over the country and in Southeast, Asia, Africa etc.

Concrete grinding machine

We had been engaged in developing and manufacturing floor polishing machines, floor washing machines, vacuum cleaners, floor scarifier, diamond tools and various accessories. We have our own manufacture bases in Tianjin and some other well cooperation partners. Some of our products have passed the CE, ISO9001 quality control system certificates.

We strongly believe that the friendship and trust given by our customers are the great treasure we have and the constant improvement & innovation in quality, cost and service will continue our group's growing.
