F7363 16K Marine Cast Iron Gate Valve

F7363 16K Marine Cast Iron Gate Valve
Price: US $ 30/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T
Product Description
Marine cast steel gate valve used in shipbulding.

Applicable Scope:
The products are used for controling the medium to open and close, preventing refluence in fuel iol piping, lubricating oil piping, water piping and steam piping at temperatures 120C or less.
Dimensions of flange are according to JIS B2220 flange dimensions of steel pipe.

Type: JIS 7363C 5K/ JIS7366 10K

JIS7363C 5K type:
Size: DN50-DN400
Normial Pressure: 0.49Mpa
Seal Pressure: 0.76Mpa
Intensity Pressure: 1.03Mpa

JIS7366 10K type:
Size: DN50-DN400
Normial Pressure: 0.49Mpa
Seal Pressure: 0.76Mpa
Intensity Pressure: 1.03Mpa
Part Name Material
Body, Bonnet Cast Steel
Disc, Seat Stainless Steel
Stem Stainless Steel
Packing Flexible Graphite
Prod Model: F7363
Established in 2001, Qingdao Junzheng Machinery Manufacture Co., Ltd. is located in the economy dynamic and beautiful coastal city Qingdao, it covers more than 10, 000 square meters of area (7, 000 m2 construction area) and with more than 80 employees (including qualified engineer 5 people, qualified QC 3 people), specialized in casting iron parts and valve manufacture more than 15 years history, it already has become a professional iron foundry and valve manufacturer which can provide OEM orders processing, newly-designed products development and after services programs. And our factory already has been licensed to export directly and legally from the year 2010.

Product materials are mainly ductile iron (GGG40 - GGG70), gray iron (GG15 - GG30), etc. We have two sets of 0.5 ton electric furnace, with advanced equipments like CNC, NC machine tool, milling machine, drilling machine, heat treatment machine. Foundry capacity could be 3, 000 MT per year.

With the company principal: Assembling power, casting perfect products. Choose Junzheng means choose success. Tell us what you need; We are going to do it for you.
