Electric Battery Power Scissor Lift Self propelled Mobile LiftApplication:The window clean lift applies to indoors, field or uneven
conditions. It's widely used for aerial installation and maintenance without power supply, with smooth working grounds, such as hotels, grand hall, sport stadium, large factory, workshops, warehouse, granary, bus and railway stations, hotels, and airports.
Advantage:1. Load weight: 300kg 500kg
2. lift height: 4m 6m 8m 10m 12m 14m
3. Self moving, without outriggers.
4. One person can control the self propelled scissor lift up down stop and move
5. Automatic pothole protection system
6. Slide-out battery trays
7. All motion alarm
8. Roll-out extension platform
9. Grooves on underframe for easy transportation
10. LED battery condition indicator
11. Fault diagnostic system
12. Tilt level sensor
13. Manual platform lowering valve for emergency
14. Solid non-marking tires
Technical parameters: | Model No. | SJG0.3-6 | SJG0.3-8 | SJG0.3-10 | SJG0.3-12 |
| Dimensions: |
| Max. Platform Height | 6m | 8m | 10m | 11.8m |
| Max. Working Height | 8m | 10m | 12m | 13.8m |
| Height ( platform stowed ) | 2.03m | 2.13m | 2.33m | 2.53m |
| Height ( guardrail fold stowed ) | 1.58m | 1.68m | 1.88m | 2.08m |
| Platform Size | 2.3 m * 1.15m | 2.3 m * 1.15m | 2.3 m * 1.15m | 2.3 m * 1.15m |
| Platform Extend Length | 0.8m | 0.8m | 0.8m | 0.8m |
| Ground Clearance | 0.1m | 0.1m | 0.1m | 0.1m |
| Productivity: |
| Load Capacity | 300kg | 300kg | 300kg | 300kg |
| Load capacity on extension deck | 100kg | 100kg | 100kg | 100kg |
| Drive Speed(Platform Stowed) | 0 - 3.2km/h | 0 - 3.2km/h | 0 - 3.2km/h | 0 - 3.2km/h |
| Drive Speed(Platform Elevated) | 0 - 0.8km/h | 0 - 0.8km/h | 0 - 0.8km/h | 0 - 0.8km/h |
| Turning Radius | 2.35m | 2.35m | 2.35m | 2.35m |
| Grade-ability | 25% | 25% | 25% | 25% |
| Drives | Dual front wheel | Dual front wheel | Dual front wheel | Dual front wheel |
| Brakes | Dual rear wheel | Dual rear wheel | Dual rear wheel | Dual rear wheel |
| Tire size | 0.305 * 0.125m | 0.305 * 0.125m | 0.305 * 0.125m | 0.305 * 0.125m |
| Power: |
| Batteries | 24V DC (4 x 6V 225Ah batteries) | 24V DC (4 x 6V 225Ah batteries) | 24V DC (4 x 6V 225Ah batteries) | 24V DC (4 x 6V 225Ah batteries) |
| Motor power | 3KW | 3KW | 3KW | 3KW |
| Standards Compliance | CE / ISO | CE / ISO | CE / ISO | CE / ISO |
| Overall Net Weight | 2150kg | 2350kg | 2550kg | 2950kg |
Our services:1) We can design the window clean lift as per your requirement.
2) The most suitable window clean lift will be recommended to you once we get your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 years warranty for whole machine without man-made faults
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9)We could reply you in 2 hours after received your any questions even on weekend and holiday.Engineers are available to your country if necessary.
Shandong Lift Machinery Co., Ltd is one of the leading manufacturer of heavy duty scissor lifts and car parking lifts in China. Being in this field for over 59 years, and exported lift machine more than 17 years till 2017. Our main products are stationary scissor lift, mobile scissor work platform, car park lift, cargo elevator, disable wheelchair lift, aerial aluminum lift ladder, and mobile container loading ramps etc.
Now there are more than 116 staffs in our factory, and 10 production lines in 8 workshops. There is a engineer team focus on research, development and innovation. The biggest load weight of our scissor lift is 100tons. All the products are passed the test held by Check Station of China Special Equipment and Manufacture.
We regard ''reasonable prices, efficient production time and good after-sales service'' as our tenet, and hope to cooperate with more customers for mutual development and benefits. We sincerely welcome each potential customer to visit our factory!
