Diamond Blade Edge Cutting Tools for Stone Processing -Diamond Edge Cutting Blade for Granite and Marble

Diamond Blade Edge Cutting Tools for Stone Processing -Diamond Edge Cutting Blade for Granite and Marble
Price: Negotiable/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Block Cutting Segment For Marble
PRODUCT FEATURES:
1 The blade has good sharpness and high efficiency at the process of cutting,meanwhile,it has a long life span 2 Good cutting result:smooth cutting,flat surface and even size 3 stable cutting,narrow cutting gap,stone waste reduction

Diameter(mm)Steel core(mm)Head size(mm)Segment NumberShapeApplication
9005.024×7.5×10(13)64Z(straight)marble
10005.024×7.5×10(13)70Z(straight)marble
12005.524×8.0×10(13)80Z(straight)marble
14006.024×8.5×10(13)92Z(straight)marble
16007.024×9.5×10(13)108Z(straight)marble
18007.524×10×10(13)120Z(straight)marble
20008.024×11×10(13)128Z(straight)marble
22008.024×11×10(13)132Z(straight)marble
25009.024×12.5×10(13)140Z(straight)marble
27009.024×12.5×10(13)140Z(straight)marble
30009.324×13×10(13)160Z(straight)marble

Diameter(mm)Steel core(mm)Head size(mm)No.ShapeApplication
3002.243/40×3.2×1021RFMarble
3502.243/40×3.2×1024RFMarble
4002.643/40×3.6×1029RFMarble
4503.042/40×4.0×1032RFMarble
Other specifications are available upan request.
Silent and non-silent blades are available for choice.

Block Cutting Segment And Blade For Granite
PRODUCT FEATURES:
1 The blade has good sharpness and high efficiency at the process of cutting,meanwhile,it has a long lifespan 2 Good cutting result:smooth cutting,flat surface and even size 3 Stable cutting,narrow cutting gap,stone waste reduction 4 M-Shape segment is easy for diamond opening
Diameter(mm)Steel core(mm)Head size(mm)No.ShapeApplication
9005.024×7.0/6.2×13(15,20)64Z3T/Z3T-M (conical)Granite
10005.024×7.0/6.2×13(15,20)70Z3T/Z3T-M (conical)Granite
12005.524×7.4/6.6×13(15,20)80Z3TZ3T-M (conical)Granite
14006.024×8.0/7.2×13(15,20)92Z3T/Z3T-M (conical)Granite
14006.524×8.4/7.6×13(15,20)92Z3T/Z3T-M (conical)Granite
16007.224×9.2/8.4×13(15,20)108Z3T/Z3T-M (conical)Granite
18007.524×10/9.2×13(15,20)120Z3T/Z3T-M (conical)Granite
20008.024×11/10×15(20)128Z3T/Z3T-M (conical)Granite
22009.024×11/10×15(20)132Z3T/Z3T-M (conical)Granite
25009.024×12/11×20(30)140Z3T/Z3T-M (conical)Granite
27009.024×12/11×20(30)140Z3T/Z3T-M (conical)Granite
30009.324×13/12×20(30)160Z3T/Z3T-M (conical)Granite
35009.524×13.5/12.5×20(30)180Z3T/Z3T-M (conical)Granite

Diameter(mm)Steel core(mm)Head size(mm)No.ShapeApplication
4002.640×3.8×1028GENERAL SPLITTINGMarble
4503.040×4.2×1032GENERAL SPLITTINGMarble
5003.040×4.2×1036GENERAL SPLITTINGMarble
5503.640×5.0×1040GENERAL SPLITTINGMarble
6003.640×5.0×1042GENERAL SPLITTINGMarble
6504.040×5.5×1046GENERAL SPLITTINGMarble
7004.040×5.5×1050GENERAL SPLITTINGMarble
7504.040×5.5×1054GENERAL SPLITTINGMarble
8004.540×6.0×1057GENERAL SPLITTINGMarble
8504.540×6.0×1058GENERAL SPLITTINGMarble
Other specifications are available upan request.
Silent and non-silent blades are available for choice.






Prod Model: stone edge cutting blade
Quality: High
Used: Granite,Marble,Sandstone,Limestone,etc.
Use: Wet Cutting
Diameter: 105-3500mm
Core Size: According to Customer Requirements
Product Name: Segmented Saw Blade
Authentication: ISO9001-2008,TUV,SGS
Advantage: Fast Cutting Speed and Long Lifespan
Technology: Sinter
Machine: Block Cutting Machine,Bridge Cutting Machine ,etc,
