330B CNC Beam Saw
Working Process :
1) Working to process the raw material into the woodworking table or the automatic feeding equipment;
2) Key Indication clamp plate;
3) Start Automatic Operation,
4) Enter Automatic Operation;Automatic positioning ;
5) Automatic flush;Automatic Sawing;Automatic discharge;
6) According to the input data automatically ;
7) Finish Cutting.
Feature
1.Open full automatic operation command by the machine;
2. no manual input, simple and accurate is expected to open;
3.computer optimization and automatic command generation is expected to open saws command electronic equipment;
4.efficient management than expected, sheet utilization is high;
5.a substantial increase in production efficiency, productivity tripled.
| Specification | 330B |
| Technical parameter |
| Cutting length | 3300mm |
| Working thickness | 75mm |
| Diameter of main saw blade | 355mm |
| Diameter of saw | 25.4mm |
| Speed of main saw blade | 4800rmp |
| Vice blade speed diameter | 180mm |
| Diameter of saw blade shaft | 25.4mm |
| Vice blade speed | 6500mm |
| Saw seat forward speed | 0~60 m/min |
| Saw back speed | 60m/min |
| Feed rate | 60m/min |
| Main saw motor power | 16Kw |
| Driving motor | 2.2Kw |
| Feed motor | 1kw |
| High pressure positive blower | 2.2Kw |
| Using air pressure | 0.5~0.6Mpa |
| Overall size | 5690*5900*1870mm |
| Rack and pinion producing area | Import |
| Servo brand | Mitsubishi |
| Main saw motor power | Taiwan |
| Driving motor | Taiwan |
| Main and auxiliary saw assembly | Taiwan |
| Bearing brand | NSK |
| Electrical components | Import |
| Operator schema | Touch screen |
| Main saw, vice saw bearing | SKF |
| PLC | Mitsubishi |
| Relay | Schneider |
How quick we can get the parts from you?
As long as the problem with parts, we will send you free accessories by express, and you can get in 4~5 days.
How much support we can get for problems?
We will do our best to help you solve the problem by phone or video, also we can do the overseas services.
Manuals and electrical for drawings can made in English?
Of course, we can do that in English.
What's your warranty of this machine?
As usual, for machine is one year warranty, but no warranty for wearing parts.
What's your payment term?
30% advance payment and the balance payment should be paid before delivery but after inspection.
Qingdao High-Class Service Import & Export Co., Ltd was founded in March 2011, At present we already have three factories and our self-contained products have three models, including edge banding machine, panel saw, sanding machine, membrane machine. Our products are stable and have a price advantage, It can bring you the highest efficiency in the shortest possible time. Besides, Our current annual production capacity is also large, annual production of 500 edge machine, cutting board saw 1000, 200 membrane machine, sanding machine 500.
Due to our high quality products and professional services, we have accumulated seven international agency services. And take into account the particleboard production line, plywood production lines and packaging production lines, etc.
We have our own trade services company, currently has online service department, network development department and purchasing department.
We stick to the principle of " Quality first, service first, continuous improvement and innovation to meet the customers. We hope to be the top supplier and provide the best machines and service to customers who are in the woodworking industry. Sincerely hope to cooperate with you and creat a better future!
