2PC Carbon Steel API Flanged Ball Valve 150LB~900LBValve Floating Ball Valve With the rapid development of science and technology, production technology and continuous improvement of product structure, quickly developed into one of the main valve.the ball is widely used in long-distance pipeline, oil refining, power, paper, chemical, pharmaceutical, steel, municipal, water and other industries, the oil pipeline in the area plays an important role. The main characteristics of valve seal itself reliable, compact, easy maintenance, simple structure, with the spherical sealing surface often in closed state, the media can not easily be eroded, easy operation and maintenance for natural gas, solvents, water, acid and other general working medium.
RST VALVE is one of the professional Ball Valve Manufacturer in china. We supplies: floating ball valve,trunnion ball valve,metal seated ball valve,threaded end ball valve,butt welded ball valve,Forged steel ball valve etc, We can manufacture and supply ball valve according to your requirements Main material of the products are A105, WCB, C5,WC6, WC9,CF8, CF8M, 316 and so on. Tops Valve design by the standards of API6D, ASME, ANSI, JIS, DIN, BS, GB, etc.
Specification:
Product Name | 2 Piece API Floating Full Port Stainless Steel Flanged Ball Valve |
1. Material | SS304/316/304L/316L ( CF8/CF8M/CF3/CF3M), WCB, etc. |
2. Size | 1/2~8 inch ( DN15~DN200) |
3. Thread standard | ISO9001 & CE, TS |
4. Port | Full Port |
5. Working Pressure | 150LB~1500LB |
6. Connection Ends | Flange |
7. Working Temp. | -20~300ºC, or according to customer requirements for different industry. |
8. Suitable Medium | Water, Natural Gas, Oil and some corrosive liquid |
9. Operated | Handle operated, Locking device is option |
10. Inspection & Testing | According to API598 |
Shipment | |
Delivery Time | 15~20 Days |
Package | Standard Exporting Plywood Case |
Shipping Port | Ningbo/Shanghai, China |
Shipping Terms | Exw, FOB, CFR, CIF, etc. |
Payment Terms | T/T, Western Union, PayPal, etc. |
| 30% prepayment, 70% balance paid before shipping or against copy of BL |
Country of Origin | Wenzhou city, China |
Production Capacity | 6000 ton/year |
MOQ | 10 PCS/size |
Technical Specification:
Design & Manufacture standard: API 6D, API 608, BS 5351.
Pressure & Temperature standard: ASME B16.34.
Face to face dimension standard: ASME B16.10.
Flange standard: ASME B16.5, ASME B16.47.
Test & Inspect standard: API 598, API 6D.
Product Feature:Floating ball, full bore or reduce bore.
ISO5211 mounting pad for option.
Blow-out proof stem design.
PTFE/RPTFE seat seal( Seat seal material could be decided by customer's request or according to valve's medium & temp. condition).
Fire-proof and anti-static design if need.
Operation: Hand wheel, Worm wheel, Pneumatic actuator & Electric Actuator.
Competitive Advantage:An ISO9001 ,CE certified manufacturer
GOOD QUALITY
RESONABLE PRICE
ON-TIME DELIVERY
STRICT EXAMINATION
SINCERE SERVICE
DURABLE IN USE
Export experience for many years
We provide you best solutions to assist you win the markets.
Material List: Item No | Part Name | Material |
1 | Nut | SS304 |
2 | Stud | SS304 |
3 | Cap | CF8M/CF8/ WCB |
4 | Body Gasket | PTFE/RPTFE |
5 | Seat | PTFE/RPTFE |
6 | Ball | SS316/SS304 |
7 | Body | CF8M/CF8/ WCB |
8 | Thrust Washer | PTFE |
9 | Stem Packing | PTFE |
10 | Stem | SS316/SS304 |
11 | Stop Cap | SS304 |
12 | Bolt | SS304 |
13 | Locking Pin | SS304 |
14 | Locking Nut | SS304 |
15 | Handle | Plastic |
16 | Stop Washer | SS304 |
