Anping Factory of 2X1X1 Galvanized / PVC Coated Wire Mesh Gabion

Anping Factory of 2X1X1 Galvanized / PVC Coated Wire Mesh Gabion
Price: US $ 12.86-13.56/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 200/Piece
Pay Type: L/C,T/T,Western Union,Paypal,Money Gram
 Hexagonal Wire mesh Gabion / Galvanized Gabion/ Gabion Box/ Gabion Basket / Stone Cage Gabion/ Gabion Wall

 China Anping Hexagonal Wire mesh Gabion is made of hexagonal double twist woven wire mesh

 Gabion baskets filled with stone
 Keywords: Gabion, gabions, Gabion cage / gabion basket

Gabion Mesh wire dia: 2.0mm-4.0mm
Gabion Mesh size: 6x8cm, 8x10cm, 10x12cm, 12x15cm, 16x18cm
Gabion body Size: 1x1x1m, 2x1x1m, 3x1x1m, 4x1x1m, 2x1x0.5m, 4x1x0.5m
Gabion Selvedge wire diameter: 3.2mm-4.2mm
Gabion Lacing/tie wire: 2.2mm/3.2mm
Weave style: Double twist hexagonal mesh
 Finish can be hot-dipped galvanized, galvanized aluminum alloy or PVC coated, etc.

Gabion basket are wire fabric containers, uniformly partitioned of variable size, interconnected with other similar containers and filled with stone at the site of use to form flexible, permeable, monolithic structures such as retaining walls, sea walls, channel linings, revetments and weirs for earth retention. Gabion basket are cages, cylinders, or boxes filled with soil or sand that are used in civil engineering, road building and military application.

Gabion basekt structures yield to earth movement but maintain full efficiency. They are quite unlike rigid or sem-rigid structures which may suffer catastrophic failure when even slight changes occur in their foundations. Highly permeable, the gabion structures act as self draining units which "bleed" off ground waters, relieving hydrostatic heads. Interstitial spaces in the rock fill dissipate the energy of flood currents and wave action. Efficiency in gabion structures, rather than decreasing with age, actually increases.

Gabion baskets Surface Treatment:
Heavily zinc galvanised wire
As above plus heavy duty PVC coating
Galmac (galfan) coated with a 95%Zinc + 5% Aluminium Mischmetal Alloy
As above plusheavy duty PVC coating

Advantages of Gabion basket:

* Permeability of the front face, ensuring drainage of backfill and no hydrostatic pressures behind the wall
* Flexibility, ensures the woven mesh gabions accommodate different settlements unlike rigid systems, for example, welded mesh cages
* Monolithic and flexible structures
* Tolerates differential settlement
* Uniform wire coating for extra durability
* Permeable structures
* One of the most economical retaining systems on the market
* Incorporation as required of vegetation throughout the structure

Gabion baskets Applications:
* Soil erosion is an ever present problem and gabions have proved to be a lasting solution around the world. The lasting appeal of gabions cage lies in their inherent flexibility.

* The most common civil engineering use of gabions cage is to stabilize shorelines or slopes against erosion. Other uses include temporary floodwalls, to filter silt from runoff, for small or temporary/permanent dams.

* In civil engineering a gabion wall is a retaining wall made of rectangular containers basketsfabricated of heavily galvanized wire, which are filled with stone and stacked on one another, usually in tiers that step back with the slope rather than vertically.
Standard Gabion Size
Length(m)Width(m)Height(m)Cells
1.01.01.01
1.51.01.01
2.00.50.52
2.01.00.52
2.01.01.02
3.01.00.53
3.01.01.03
4.01.01.04
4.01.01.04
Custom sizes are also available








Contacter:

Tina
(Sales manager)
Mobile: +86-15230850747



www.yc-wiremesh.com
http://hongdawiremesh.en.made-in-china.com
Prod Model: XM-00B
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Gabion Size: 2mx1mx1m, 0.5mx1mx1m, 3mx1mx1m, 4mx1mx1m
Gabion Wire Gauge: 2.0mm-4.0mm
Selvedge Wire: 3.0-4.5mm
Lacing Wire: 2.2mm
Tensile Strength: 300-750n/Sqm
Gabion Mesh Shape: Hexagonal, Square, or Rectangle
Gabion Standard: En1002-4, ASTM97
Zinc Coating: 40-270g/Sqm
Diaphgram: 1m
Certificates: ISO9001, SGS, BV, Pvoc
Material: Low Carbon Steel Wire
Application: Construction Wire Mesh
Hole Shape: Hexagonal
Usage: Military Applications
Technics: Woven
Surface Treatment: Galvanized
Size: 2m x 1m x 1m
Aperture: 60*80mm, 80*100mm, 80*120mm, 100*120mm, 120*150mm
Anping Xingmao Metal Wire Mesh Co., Ltd. is located at Anping County, Hebei Province, the famous Wire Mesh Town in China. XingMao is a one of the 5 biggest wiremesh companys in China, has advanced technology and equipment of production, test and inspection. The products are all inspected by our professional inspection team. We can design and develop different wire mesh products upon customers requirements or drawings.

Our main products include:

Gabion basket,

Gabion box,

Security Fence,

Garrison Fencing,

Perforated metal sheet,

Stainless steel wire mesh,

Galvanized iron wire,

Black annealed wire,

Alumium alloy wire mesh,

Brass wire mesh,

Copper mesh etc,

Which are widely applied in petroleum, chemical, food, construction and other industries.

Our export amount is up to 65, 000.00 dollars averagely per month. We mainly export to Europe, America, South Amercia, East and south Asia, MID east district, and some parts Africa countrys. With a dozen of years, we have entered into steady business with hundreds of customers at home and abroad.

General Manager, on behalf of all employees of Xing Mao, warmly welcomes you contact us for further information! We trust we can cooperate well based on mutual benefit and trust!
