Home Toolbuy Products 5L Oil Can Blowing Shaping Molds

5L Oil Can Blowing Shaping Molds

5L Oil Can Blowing Shaping Molds
Price: US $ 800-2500/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T









Extrusion blow mold
2. High grade quality bottle mould
3. Expert cooling system design.
4. With long life
Advantage

Skilled Language to ensure good communion
Special in exported mould, experienced in international standard
Rational mould design to extend mould life, and to get high production efficiency,
Precision Machining to fine parting line effect

Blow molding machine adopt Mitsubishi PLC of Japan as Central Processor Unit.
Mitsubishi Motor Servo system is adopted to do high speed location.
It's very easy and convenient for Human-computer interface to operate and control the machine.
It could control each running of the system in any time, automatically test malfunctions, which is convenient to maintain the machine

Description

HDPE  blow mould

Material

Blow plate is in Stainless steel.
Base plate in 50# steel with Ni plating.

Cavity material

steel P20, Aluminium , S136 or Steel 2316

Deflashing systemAvaialble
TreatmentHeat treatment SRC40
Mould size

bottle volume accordingly

Package

Wooden box

Delivery time

30~40 working days
GuaranteeMin 2 million shots





DescriptionPlastic injection mould
Mould baseHASCO, DME, LKM
Tool steel45#/50#/P20/718/H13/2738/2316/S136/NAK80 etc.
Product materialPP,PC,PE,ABS,PPR,PVC or others
Design softwareProe, CAD, UG
RunnerHot/Cold
Cavity No.1*N
Surface treatmentTexturing and polishing
Hot treatmentTempering, quenching, nitriding
GateSide gate, direct gate, pin point gate, submarine gate
Mould life2 million shots, Depends on material and workmanship
MOULD doff wayDoff plate, ejectors, air valves, hydraulic jar
PackageExport wooden cases
Delivery methodBy sea or air
Delivery time40-45 workingdays
Place of originJiangsu China
Quality assurance0ne year guarantee
SpecificationAccording to customer's requirements
Prod Model: Blowing Mould
Auto-Deflashing: Available
Mould-Testing: Yes
Cooling System: Separate Cooling System
Delivery Time: 40~45workig Days
Mould Grantee: Min 2 Million Shots
Assembling: Neck Part and Bottom Part Removable
Cavity: Single or Multiple Cavity
Applications: Bottles,Jars,Jerry Cans,Gallons,Containers
Treatment: Heat Treatment Src40~45
Tradename: Dawson
Shaping Mode: Blowing Mould
Process Combination Type: Single-Process Mode
Application: Hardware
Installation: Fixed
Runner: Auto-Deflashing Mould
DAWSON MACHINERY & MOULD GROUP, located in Zhangjiagang city, our team have more than 15 years' experience in the field of

Plastic blow molding machines, Plastic Moulds, IBM machines, injection molding machines, PET blow moldings and other accessory machines in this filed.

Our machines is capable to produce all kinds of plastic bottles, jerry cans, jars, gallons, toys, balls, kettles, drums, barrels, tools, containers, pallets...

The material can be HDPE, PP, PS, PC, PET, PETG, TPU, LDPE, ABS, PVC, PA...So on, and the size of plastic containers starting from 5ml to max 3000L.

We also have professional mould making workshop for all kinds of mould manufacturing, mould testing equiments. We have strict quality control and inspection system, make sure each mould is properly tested and guarantee its reliablity and good quality.

We can provide complete solution for your plastic industry business, as well as all sorts of technical support & after-sale services! Provide you the complete and turn-key solution to help you start plastic molding business.

Our engineers are all having more than 6years, and they are able to sent to you to help with the installations, trainings and all sorts of technical supports.

We already have customers in more than 45 countries, and had successfully supplied machinery & moulds to customers such as Total, GULF, YAMAHA, MengNiu, Loreal… DAWSON will be your reliable friend in China, and we will always do our best to support you and help with your business.
