Home Toolbuy Products 4G Lte Chipset SMS Wireless Router Supports FDD- Lte. B1, B3, B7, B8, B20, B28 /Tdd-Lte B38, B40

4G Lte Chipset SMS Wireless Router Supports FDD- Lte. B1, B3, B7, B8, B20, B28 /Tdd-Lte B38, B40

4G Lte Chipset SMS Wireless Router Supports FDD- Lte. B1, B3, B7, B8, B20, B28 /Tdd-Lte B38, B40
Price: US $ 95-115/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union,Money Gram
Contact Supplier
Shenzhen Head Weblink Technology Co., Ltd.
Showroom Product Company Profile
4g LTE chipset SMS Wireless Router supports FDD- LTE. B1,B3,B7,B8,B20,B28 /TDD-LTE B38,B40

Product feature.

• 4G LTE data transmission;

• Active auto connect;

• Embedded watchdog , Auto recovery;

• 2*2  4G/WIFI MIMO antenna;

• 4G LTE antenna gain: >10DBi

• Integrate 4G LTE feature;

• One LAN port;

• Supported communication protocols: PPTP,L2TP,IPSEC VPN,DDNS,TR-069,GRE,DHCP,HTTP,HTTPS, SSH,TCP,UDP,Open VPN,SNMP;

• POE power supply,

• With SIM card slot;

• Remote management platform;

• Firmware version:  Linux;

• Waterproof,dustproof,lightning protection. Protection level, IP67

• Operating Temperature.  -40ºC -- +80ºC

• Operating humidity. 5%--95%

Frequency bands

  Version A

      LTE FDD. B2,4,5,17

      UMTS. 850/1900MHz

Version E

      LTE FDD. B1,3,7,8,20

      LTE TDD B38, B40

      UMTS. 900/2100MHz

      GSM. 900/1800MHz

Version C

      LTE FDD. B1,3,7,8

      LTE TDD B38, B39, B40, B41

      UMTS. 900/2100MHz

      TD-SCDMA. 1880~1920MHz & 2010~2025MHz

      GSM. 900/1800MHz

Version JC

      LTE FDD. B1,B3,B8,B18,B19

      LTE TDD. B41

      UMTS. B1,B6,B8

      GSM. 900/1800MHz

Version JE

      LTE FDD. B1,B8

      UMTS. B1,B8

      GSM. 900/1800MHz


 Data rate

FDD LTE. DL,100Mbps  UL,50Mbps

        TDD LTE. DL,50Mbps    UL,25Mbps

        WCDMA. DL 42Mbps   UL5.76Mbps

        TD-SCDMA.  DL 2.8Mbps  UL 2.2Mbps



*Note.

      We can provide customized frequency bands for customers.





Prod Model: HDR100 L1
Waterproof Level: IP67
Work Mode: AP+STA
WiFi Antenna Type: Built-in
Transmission Rate: 101-150Mbps
Certification: CE
Type: Wireless Router
Voltage: +5V~48V
Antenna Gain: 10~13dBi
Color: White
Head Weblink Corporation is founded in 2008. We are expert of wireless M2M products and total solutions supplier in China. Since our foundation, we have focused on M2M data transmission field. Especially, we are the professional industrial 3G/4G LTE router, 3G/4G CPE, 2G/3G/4G LTE modem manufacturer and 2G/3G/4G LTE wireless module distributor. Our products and solutions are widely used in finance, transportation, telecom, electricity, power meter, water conservancy and other industrialapplications. Up to now, we have exported our products to more than 70 countries.

Head Weblink commit ourselves to providing the product with high-reliable quality and best service for our customers in order to help them to stay competitive in their business market.

Uphold the faith of 'quality first, professional focus, service first', Head Weblink will continuously to strengthen the research and development of communication technology and innovation. Improve their own products, rich products, to ensure that customers get efficient, stable, long-term service and supply safety.
