Features:★The sound quality of the performance of real and natural;
★Its biggest feature is the lightweight and has a high sound pressure level, to meet the needs of small speakers and large space occasions.
★Durable appearance, the use of high-density birch plywood as the structure of the box material, and the box surface with a high degree of durability of the black polyurethane paint.
★Anti-aging strength is very strong.
★Application areas: conference room, multi - function hall of the main sound;
Indoor SHOW, slow shake it; restaurants, shopping malls and other indoor venues;
The main technical parameters:
Rated power: 200W;
Maximum input power: 400W;
Impedance: 8Ω;
Frequency response: 50Hz-20KHz;
System type: 10-inch two-way two-cell full frequency;
Tweeter: 34 core treble × 1;
Woofer: 10 inch bass × 1;
Standard coverage angle: 90 ° (H) x50 ° (V);
Maximum sound pressure level: 125dB;
Sensitivity (1W / 1m): 96dB / W (lm);
Connector: SPEAKON NL4 × 1 PIN1 + / 2 + POS. PIN1- / 2-NEG (plus or minus 4-pin safety plug);
Hanging hardware: 8xM8 hanging point, base care;
Material and surface treatment: plywood, environmentally friendly water-based paint;
Colour: Black;
Packaging & Shipping★Product Size: 530 * 330 * 330 (unit: mm)
★Packing size: 630 * 400 *420 (unit: mm)
★Net Weight: 18kg / pcs.
★Gross Weight: 19kg / pcs
Payment termSmaple:T/T 100% deposit before delivery.
Mass production: T/T 30%deposit in advance
Delivery timeSample:3 days
Mass production:5-7 day,depand on quantity
| Product Name | Powerful 350w 1.75 inch tweeter full frequency PA sound system speaker club theater pc speaker |
| Item No. | XL-F10 | XL-F12 | XL-F15 | XL-GF15 |
| Raterd Power | 200W | 300W | 350W | 400W |
| Max Input Power | 400W | 600W | 700W | 800W |
| Impedance | 8Ω |
| Frequency Response | 50Hz-20KHz | 55Hz-19.7KHz | 45Hz-20KHz | 35Hz-19KHz |
| System Type | 10 inch, two channel, two unit, full-frequency | 12 inch, two channel, two unit, full-frequency | 15 inch, two channel, two unit, full-frequency | 15 inch, two channel, two unit, full-frequency |
| Tweeter Unit | 1.5 inch tweeter * 1 | 1.75 inch tweeter * 1 | 1.75 inch tweeter * 1 | 3 inch tweeter * 1 |
| Woofer Unit | 10 inch woofer* 1 | 12 inch woofer* 1 | 15 inch woofer* 1 | 15 inch woofer* 1 |
| Standard coverage angle | 90°(H) * 50°(W) |
| Max SPL | 125dB | 127dB | 129dB | 132dB |
| Sensitivity(1W/1m) | 96dB/W(1m) | 98dB/W(1m) | 99dB/W(1m) | 102dB/W(1m) |
| Connector | SPEAKON NL4*1 PIN1+/2+POS. PIN1-/2-NEG(plus/minus 4 cores plugs) |
| Suspension Hardware | 10*M8 suspension point, base |
| Material | plywood | 18mm plywood |
| Surface treatment | environmental protection water based paint |
| Color | Black |
| Product Size(mm/pc W*D*H ) | 330*330*530 | 380*365*600 | 430*450*670 | 430*450*670 |
| Net Weight | 18KG | 24KG | 30KG | 30KG |
